LFE5U-12F-6BG256I
IC FPGA 197 I/O 256CABGA
- 產品分類
- FPGA - 現場可程式化閘陣列
- 封裝
- 256-LFBGA
- 庫存
- 2,013 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Lattice Semiconductor Corporation |
|---|---|
| 產品分類 | FPGA - 現場可程式化閘陣列 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 100°C (TJ) |
| Package | Tray |
| Product status | Active |
| Series | ECP5 |
| Supplier Device Package | 256-CABGA (14x14) |
| Voltage - Supply | 1.045V ~ 1.155V |
| 資料表 | 查看資料表PDF |
採購概覽
LFE5U-12F-6BG256I 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
LFE5U-12F-6BG256I 詳細描述
Product Overview
The LFE5U-12F-6BG256I is a Lattice Semiconductor Corporation ECP5 field programmable gate array (FPGA) device in a 256-LFBGA Surface Mount package, with the 256-CABGA (14x14) package designation. The device provides 197 I/O, 12000 logic elements/cells, 3000 LABs/CLBs, and 589824 total RAM bits. Its specified supply voltage range is 1.045V ~ 1.155V, and its operating temperature range is -40°C ~ 100°C (TJ). These characteristics support configurable digital logic and interface management in compact board-level designs.
Key Features
- 197 I/O for external connectivity and configurable interface support.
- 12000 logic elements/cells and 3000 LABs/CLBs for programmable digital logic implementation.
- 589824 total RAM bits for on-device data storage and buffering.
- 256-LFBGA Surface Mount package, with 256-CABGA (14x14) package designation.
- Supply voltage range of 1.045V ~ 1.155V.
- Operating temperature range of -40°C ~ 100°C (TJ).
Applications
- Embedded control logic where programmable digital functions replace fixed-function logic.
- Sensor and peripheral interface aggregation for data acquisition boards.
- Digital signal routing and logic sequencing between board-level subsystems.
- Custom data path or logic implementation in FPGA-based designs.
Design & Procurement Notes
Designers should plan for the 1.045V ~ 1.155V supply range, Surface Mount assembly, and the 256-LFBGA / 256-CABGA (14x14) footprint when laying out the board. The 197 I/O count, 12000 logic elements/cells, 3000 LABs/CLBs, and 589824 total RAM bits define the available programmable resources and should be mapped against required functions, interface pins, and on-device buffering. The -40°C ~ 100°C (TJ) operating range should be considered during thermal design and junction-temperature budgeting. For procurement, specify the exact part number and package designation to match the intended board footprint and assembly process.
