LCMXO2280E-5TN144C

Product Overview

The LCMXO2280E-5TN144C from Lattice Semiconductor Corporation is a MachXO field programmable gate array (FPGA) intended for embedded logic integration. It provides 2280 logic elements or cells, 285 LABs or CLBs, and 28,262 total RAM bits within a 144-LQFP package. The device exposes 113 input/output pins and is specified for surface-mount assembly. Its supply voltage range is 1.14 V to 1.26 V, and its operating junction temperature range is 0°C to 85°C. The part supports designs that need configurable digital logic, local memory resources, and a 144-LQFP package footprint.

Key Features

• MachXO FPGA architecture with 2280 logic elements or cells and 285 LABs or CLBs
• 28,262 total RAM bits for embedded data storage and buffering
• 113 I/O pins in a 144-LQFP package, with 144-TQFP (20x20) package designation
• Surface-mount package for PCB assembly
• Supply voltage range of 1.14 V to 1.26 V
• Operating temperature range of 0°C to 85°C (TJ)

Applications

• Embedded control logic in instrumentation and measurement equipment
• Interface bridging and logic adaptation in electronic assemblies
• Glue logic replacement and configurable pin mapping in board designs
• Local data buffering and state-machine implementation using on-chip RAM

Design & Procurement Notes
