LCMXO2-4000HC-5QN84C
IC FPGA 68 I/O 84QFN
- 產品分類
- FPGA - 現場可程式化閘陣列
- 封裝
- 84-VFQFN Dual Rows, Exposed Pad
- 庫存
- 1,371 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Lattice Semiconductor Corporation |
|---|---|
| 產品分類 | FPGA - 現場可程式化閘陣列 |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 85°C (TJ) |
| Package | Tray |
| Product status | Active |
| Series | MachXO2 |
| Supplier Device Package | 84-QFN (7x7) |
| Voltage - Supply | 2.375V ~ 3.465V |
| 資料表 | 查看資料表PDF |
採購概覽
LCMXO2-4000HC-5QN84C 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
LCMXO2-4000HC-5QN84C 詳細描述
Product Overview
LCMXO2-4000HC-5QN84C is a Lattice Semiconductor Corporation MachXO2 field programmable gate array (FPGA) supplied in an 84-VFQFN dual-row package with an exposed pad. The device provides 4320 logic elements or cells, 540 LABs or CLBs, 94208 total RAM bits, and 68 I/O pins for embedded programmable logic designs. It is a surface-mount IC intended for operation with a supply voltage range of 2.375 V to 3.465 V and a junction temperature range of 0°C to 85°C.
Key Features
- MachXO2 FPGA with 4320 logic elements or cells and 540 LABs or CLBs.
- Includes 94208 total RAM bits for on-chip storage in programmable logic designs.
- Provides 68 I/O pins in an 84-QFN (7x7) surface-mount package.
- Operates from a 2.375 V to 3.465 V supply and specifies a 0°C to 85°C junction temperature range.
- Uses an 84-VFQFN dual-row package with exposed pad for surface-mount board layouts.
Applications
- Programmable glue logic replacement in embedded board-level systems.
- Peripheral interface adaptation using the available 68 I/O pins.
- Small on-chip buffering or state storage using the embedded RAM bits.
Design & Procurement Notes
For design use, confirm that the board power rail remains within the 2.375 V to 3.465 V supply range and that thermal calculations keep the junction temperature within 0°C to 85°C. The 84-VFQFN dual-row exposed-pad package requires appropriate pad, thermal, and routing layout for surface-mount assembly. The 68 I/O count should be mapped against required external signals, while the 4320 logic elements or cells, 540 LABs or CLBs, and 94208 total RAM bits define the available programmable logic and on-chip memory capacity. Procurement should specify the exact manufacturer part number LCMXO2-4000HC-5QN84C to preserve the specified package and device.
