MC34PF3001A3EPR2
POWER MANAGEMENT IC I.MX7 PRE-
Quick Answer: The MC34PF3001A3EPR2 is a power management IC from NXP USA Inc.
- Manufacturer
- NXP USA Inc.
- Product Category
- Specialized Power Management ICs (PMICs)
- Package
- 48-VFQFN Exposed Pad
- Stock
- 1,453 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | NXP USA Inc. |
|---|---|
| Product Category | Specialized Power Management ICs (PMICs) |
| Applications | Processor |
| Min Qty | 4000 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 105°C |
| Package | Tape & Reel (TR) |
| Product status | Active |
| Supplier Device Package | 48-HVQFN (7x7) |
| Voltage - Supply | 2.8V ~ 5.5V |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for MC34PF3001A3EPR2.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for MC34PF3001A3EPR2
Product Overview
The MC34PF3001A3EPR2 is a power management IC from NXP USA Inc. intended to support processor-based systems. The device is described for use with i.MX7, providing a power architecture with three buck converters, six low-dropout regulators, and an always-on supply. It operates from a 2.8 V to 5.5 V supply and is specified for a -40°C to 105°C operating temperature range. The component uses a 48-VFQFN exposed-pad package, with a 48-HVQFN (7x7) package designation, and is intended for surface-mount assembly. The device combines multiple regulated outputs in one surface-mount package.
Key Features
- Power management IC for i.MX7 processor systems.
- Three buck converters and six low-dropout regulators.
- Always-on supply function.
- Supply voltage range: 2.8 V to 5.5 V.
- Operating temperature range: -40°C to 105°C.
- 48-VFQFN exposed-pad package with 48-HVQFN (7x7) package designation.
- Surface-mount mounting type.
Applications
- Powering i.MX7 processors in embedded computing boards.
- Generating multiple regulated rails for processor-based control boards.
- Maintaining always-on power functions in processor-oriented system designs.
Design & Procurement Notes
When selecting the MC34PF3001A3EPR2, verify that the system supply falls within 2.8 V to 5.5 V and that thermal conditions remain within -40°C to 105°C. The 48-VFQFN exposed-pad package and 48-HVQFN (7x7) package designation require surface-mount assembly and layout compatible with the exposed pad. The three buck converters, six low-dropout regulators, and always-on supply should be mapped to the required processor power domains and standby functions. Confirm compatibility with the i.MX7 power management requirements before finalizing the schematic.
