MC34704AEP
IC POWER MANAGEMENT 56-QFN
Quick Answer: MC34704AEP is a power management integrated circuit from NXP USA Inc.
- Manufacturer
- NXP USA Inc.
- Product Category
- Specialized Power Management ICs (PMICs)
- Package
- 56-VFQFN Exposed Pad
- Stock
- 2,460 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | NXP USA Inc. |
|---|---|
| Product Category | Specialized Power Management ICs (PMICs) |
| Applications | Processor |
| Current - Supply | 86mA |
| Min Qty | 1 |
| Mounting Type | Surface Mount |
| Operating Temperature | -20°C ~ 85°C |
| Package | Tray |
| Product status | Active |
| Supplier Device Package | 56-QFN-EP (7x7) |
| Voltage - Supply | 2.7V ~ 5.5V |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for MC34704AEP.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for MC34704AEP
Product Overview
MC34704AEP is a power management integrated circuit from NXP USA Inc. intended for processor applications. The device is supplied as a surface-mount 56-VFQFN exposed-pad package, with a package of 56-QFN-EP measuring 7 mm by 7 mm. It operates from a supply voltage range of 2.7 V to 5.5 V and has a specified supply current of 86 mA. The operating temperature range is -20°C to 85°C. This IC is suitable for compact board designs that require a processor power management component in a 56-pin QFN footprint.
Key Features
- Processor-focused power management IC from NXP USA Inc.
- Supply voltage range: 2.7 V to 5.5 V
- Supply current: 86 mA
- Operating temperature range: -20°C to 85°C
- Surface-mount 56-VFQFN exposed-pad package, 56-QFN-EP (7x7)
Applications
- Embedded computing platforms with processor power management requirements
- Application processor power management in compact board designs
- Processor subsystems operating from 2.7 V to 5.5 V supply
Design & Procurement Notes
When selecting MC34704AEP, verify that the system supply falls within 2.7 V to 5.5 V and that the operating environment remains within -20°C to 85°C. Include the 86 mA supply current in overall power budget calculations. Because the device uses a surface-mount 56-VFQFN exposed-pad package, the PCB land pattern, solder paste design, and assembly process must match the 56-QFN-EP (7x7) footprint. Use the exact manufacturer part number and package when checking design files, layout, and procurement records during component selection.
