ICE40LP1K-CB121
IC FPGA 92 I/O 121CSBGA
- 產品分類
- FPGA - 現場可程式化閘陣列
- 封裝
- 121-VFBGA, CSBGA
- 庫存
- 1,461 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Lattice Semiconductor Corporation |
|---|---|
| 產品分類 | FPGA - 現場可程式化閘陣列 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 100°C (TJ) |
| Package | Tray |
| Product status | Active |
| Series | iCE40™ LP |
| Supplier Device Package | 121-CSBGA (6x6) |
| Voltage - Supply | 1.14V ~ 1.26V |
| 資料表 | 查看資料表PDF |
採購概覽
ICE40LP1K-CB121 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
ICE40LP1K-CB121 詳細描述
Product Overview
The ICE40LP1K-CB121 is a Lattice Semiconductor Corporation iCE40 LP field programmable gate array intended for embedded digital logic. The device provides 92 input/output signals, 1280 logic elements/cells, and 160 LABs/CLBs, with 65536 total RAM bits for on-chip storage and buffering. The package is a 121-VFBGA, CSBGA package with a 121-CSBGA (6x6) body, and it is mounted using surface-mount techniques. The supply voltage range is 1.14V to 1.26V, and the junction operating temperature range is -40°C to 100°C.
Key Features
- 1280 logic elements/cells and 160 LABs/CLBs define the programmable logic capacity of the iCE40 LP device.
- 65536 total RAM bits are available for on-chip data storage, buffering, or state holding within user logic.
- The FPGA provides 92 I/O signals for external interfacing in a 121-VFBGA, CSBGA package.
- Supply voltage is 1.14V to 1.26V, and junction temperature operation is -40°C to 100°C.
- The 121-CSBGA (6x6) surface-mount package supports board-level placement in embedded designs.
Applications
- Embedded control logic where user-defined state machines and glue logic replace discrete components.
- Sensor and peripheral interfacing that requires multiple digital I/O signals and simple data formatting.
- On-chip buffering or small data-path storage using available RAM bits within a logic design.
- Custom digital processing blocks for equipment interfaces, timing generation, or protocol conversion.
Design & Procurement Notes
Designers should account for the 1.14V to 1.26V supply range and the -40°C to 100°C junction temperature limit when planning power delivery and thermal behavior. The 121-VFBGA, CSBGA package with a 121-CSBGA (6x6) body requires a matching surface-mount land pattern and soldering process. The 92 I/O count, 1280 logic elements/cells, 160 LABs/CLBs, and 65536 total RAM bits define the available logic, storage, and external interface budget, so these limits should be checked against the intended block diagram before finalizing the board layout.
