FS200R12KT4R

Product Overview

FS200R12KT4R is an Infineon Technologies EconoPACK™ 3 sixpack IGBT power module designed for high-performance industrial motor control and power conversion applications. It features Infineon TRENCHSTOP™ IGBT4 technology with optimized switching characteristics, low conduction losses and an integrated NTC temperature sensor for thermal monitoring. With a 1200V collector-emitter voltage rating and 200A continuous collector current capability, this module provides high power density and reliable operation for general-purpose motor drives, servo systems and industrial inverter applications.

Key Features

• Manufacturer: Infineon Technologies

• Part Number: FS200R12KT4R

• Product Type: IGBT Power Module

• Series: EconoPACK™ 3

• Configuration: Sixpack (Three-Phase Bridge)

• Technology: TRENCHSTOP™ IGBT4 - T4

• Collector-Emitter Voltage (VCES): 1200V

• Continuous Collector Current (IC): 200A

• Maximum Collector Current (IC): 200A

• Repetitive Peak Collector Current (ICRM): 400A

• Collector-Emitter Saturation Voltage (VCE(sat)): 1.75V typical

• Diode Forward Voltage (VF): 1.7V typical

• Gate-Emitter Voltage (VGES): ±20V

• Operating Junction Temperature: Up to 150°C

• Integrated Components: Six IGBT chips, six freewheeling diodes and NTC temperature sensor

• Package Type: EconoPACK™ 3 (AG-ECONO3B)

• Package Dimensions: Approximately 122mm × 62mm

• Substrate Material: Al₂O₃ ceramic substrate

• Base Plate Material: Copper base plate

• Mounting Type: Screw mounting / solder connection

• Cooling Method: Heatsink cooling

• Isolation Design: Electrically isolated base plate

• Qualification: Industrial grade

• Packaging: Tray

• Compliance: RoHS compliant

• Features: Low VCE(sat), high power density, excellent thermal performance and reliable switching capability

Applications

FS200R12KT4R is designed for industrial power electronics systems requiring high current capability and efficient switching performance. Typical applications include general-purpose motor drives, servo motor drives, industrial automation equipment, inverter systems, pumps, fans, compressors and other high-power motor control applications.

Quality & Sourcing

Antrex Electronics can support FS200R12KT4R sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For industrial power semiconductor projects, buyers can provide quantity, target price, required date code, packaging requirements and application details for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, marking verification, visual inspection and third-party testing support when required. OEMs, inverter manufacturers, industrial automation suppliers and electronic component buyers are welcome to send BOM lists or hard-to-find IGBT module requirements for sourcing assistance.
