TLP124
TLP124 is a Toshiba mini flat phototransistor optocoupler featuring high isolation voltage and reliable signal transmission for industrial control applications
- 產品分類
- 光耦合器/光電耦合器
- 封裝
- SOP4
- 庫存
- 1,500 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Toshiba Semiconductor and Storage |
|---|---|
| 產品分類 | 光耦合器/光電耦合器 |
| Applications | Programmable Controllers, AC/DC Input Modules, Solid-State Relays, Telecommunication Equipment |
| Collector Current (IC) | 50mA Maximum |
| Collector-Emitter Saturation Voltage | 0.4V Maximum |
| Collector-Emitter Voltage (VCEO) | 80V Minimum |
| Current Transfer Ratio (CTR) | 100% Minimum |
| Features | Compact Package, High Isolation, Low Input Current Operation |
| Forward Current (IF) | 50mA Maximum |
| Forward Voltage (VF) | 1.3V Typical |
| Input Type | GaAs Infrared LED |
| Isolation Voltage | 3750 Vrms Minimum |
| Mounting Style | Surface Mount Technology (SMD) |
| Number of Channels | 1 Channel |
| Operating Temperature Range | -55°C to +100°C |
| Optocoupler Type | Phototransistor Output |
| Output Type | NPN Phototransistor |
| Package Type | SOP-4 / Mini Flat Package |
| Part Number | TLP124 |
| Peak Forward Current | 1A (Pulse) |
| Power Dissipation | 200mW Maximum |
| Reverse Voltage (VR) | 5V Maximum |
| Safety Standards | UL1577 Recognized |
| Storage Temperature Range | -55°C to +125°C |
| 資料表 | 索取數據表 |
採購概覽
TLP124 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
TLP124 詳細描述
Product Overview
TLP124 is a Toshiba photocoupler featuring a GaAs infrared LED optically coupled with a phototransistor output. Designed for electrical isolation and signal transmission applications, this compact mini-flat coupler provides 3750Vrms isolation voltage, high current transfer ratio and reliable switching performance. With a small surface-mount package and high noise immunity, it is suitable for programmable controllers, AC/DC input modules, office equipment, telecommunication systems and industrial control applications.
Key Features
Manufacturer: Toshiba
Part Number: TLP124
Product Type: Photocoupler / Optocoupler
Output Type: Phototransistor Output
Input Device: GaAs Infrared Emitting Diode
Number of Channels: 1 Channel
Collector-Emitter Voltage (VCEO): 80V min.
Collector Current (IC): 50mA max.
Current Transfer Ratio (CTR): 100% min.
High CTR Rank: 200% min. available
Isolation Voltage: 3750Vrms min.
Forward Current (IF): 50mA max.
Forward Voltage: Approx. 1.15V typical
Reverse Voltage: 5V max.
Package Type: Mini Flat Coupler
Mounting Type: Surface Mount Device (SMD)
Package Configuration: 6-pin package (4 active leads)
Operating Temperature Range: -55°C to +100°C
Safety Standard: UL1577 recognized
Features: Compact size, high isolation, stable signal transmission and reliable switching performance
Typical Applications: Programmable controllers, AC/DC input modules, solid-state relays and telecommunication equipment
Datasheet: TLP124 datasheet PDF available for technical verification before production use.
Applications
TLP124 is designed for applications requiring electrical isolation between control circuits and signal interfaces. Typical applications include industrial PLC systems, factory automation equipment, AC/DC input modules, office machines, communication equipment, solid-state relay circuits and embedded control systems.
Quality & Sourcing
Antrex Electronics can support TLP124 sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, customers can provide quantity requirements, delivery schedules, application details and technical specifications for faster quotation support.
For quality assurance, Antrex Electronics can assist with product photos, marking verification, visual inspection and third-party testing services when required. OEM manufacturers, industrial equipment suppliers, repair centers and electronic component buyers are welcome to submit BOM lists or hard-to-find optoelectronic component requirements for sourcing assistance.
