I6A4W020A033V-001-R
DC DC CONVERTER 3.3-15V 250W
- 製造商
- TDK-Lambda
- 產品分類
- DC/DC 轉換器
- 封裝
- Sixteenth Brick
- 庫存
- 8,570 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | TDK-Lambda |
|---|---|
| 產品分類 | DC/DC 轉換器 |
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Control Features | Enable, Active Low |
| Current - Output (Max) | 20A |
| Efficiency | 97% |
| Features | Remote On/Off, OCP, OTP, SCP |
| Min Qty | 1 |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature | -40°C ~ 125°C |
| Package | Box |
| Power (Watts) | 250 W |
| Product status | Active |
| Series | i6A4W (250W) |
| Size / Dimension | 1.30" L x 0.90" W x 0.50" H (33.0mm x 22.9mm x 12.7mm) |
| Supplier Device Package | Sixteenth Brick |
| Type | Non-Isolated PoL Module |
| Voltage - Input (Max) | 53V |
| Voltage - Input (Min) | 9V |
| Voltage - Output 1 | 3.3 ~ 15V |
| 資料表 | 查看資料表PDF |
採購概覽
I6A4W020A033V-001-R 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
I6A4W020A033V-001-R 詳細描述
Product Overview
The TDK-Lambda I6A4W020A033V-001-R is an Active non-isolated Point-of-Load module in the i6A4W (250W) series. It accepts a 9V to 53V input and provides one adjustable output from 3.3V to 15V at up to 20A, with a rated power of 250W. The through-hole Sixteenth Brick package measures 33.0 mm L x 22.9 mm W x 12.7 mm H. The module is specified for operation from -40°C to 125°C and lists 97% efficiency. Control and protection features include active-low enable, remote on/off, OCP, OTP, and SCP. The supplied data identifies CE approval and ITE (Commercial) application context.
Key Features
- Single non-isolated PoL output adjustable from 3.3V to 15V at up to 20A.
- Input range of 9V to 53V with a 250W power rating.
- Through-hole Sixteenth Brick package with dimensions 33.0 mm L x 22.9 mm W x 12.7 mm H.
- Operating temperature range of -40°C to 125°C and efficiency value of 97%.
- Includes active-low enable, remote on/off, OCP, OTP, and SCP.
- CE approval is listed in the supplied data.
Applications
- Commercial information technology equipment power subsystems that require a single non-isolated adjustable output.
- Board-level conversion from a 9V to 53V DC input to a 3.3V to 15V load rail.
- Through-hole Sixteenth Brick integration in systems using remote on/off and protection features.
Design & Procurement Notes
Designers should confirm the desired output set point within 3.3V to 15V and verify that the 20A maximum output current and 250W rating match the load profile. Because the module is non-isolated, system grounding and reference considerations should be reviewed. The active-low enable and remote on/off control should be integrated into system sequencing, and the applicable control interface levels should be checked against the final board design. The through-hole Sixteenth Brick footprint and 12.7 mm height affect layout, neighboring components, and enclosure clearance. The -40°C to 125°C operating range and 97% efficiency should be considered with board-level thermal management. CE approval is listed; confirm the regulatory requirements of the final assembly.
