SI53102-A2-GMR
IC CLK BUFFER PCIE 1:2 8TDFN
- 產品分類
- 特定應用時脈與時序 IC
- 封裝
- 8-TDFN Exposed Pad
- 庫存
- 15,563 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Skyworks Solutions Inc. |
|---|---|
| 產品分類 | 特定應用時脈與時序 IC |
| Differential - Input:Output | Yes/Yes |
| Frequency - Max | 100MHz |
| Input | Clock |
| Main Purpose | PCI Express (PCIe) |
| Mounting Type | Surface Mount |
| Number of Circuits | 1 |
| Operating Temperature | -40°C ~ 85°C |
| Output | Clock |
| Package | Tape & Reel (TR),Cut Tape (CT) |
| PLL | No |
| Product status | Active |
| Ratio - Input:Output | 1:2 |
| Supplier Device Package | 8-TDFN (1.4x1.6) |
| Voltage - Supply | 2.25V ~ 3.63V |
| 資料表 | 查看資料表PDF |
採購概覽
SI53102-A2-GMR 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
SI53102-A2-GMR 詳細描述
Product Overview
The SI53102-A2-GMR from Skyworks Solutions Inc. is an application-specific clock buffer for PCI Express (PCIe) timing paths. Input and output are both listed as Clock, with a 1:2 input-to-output ratio, and the differential input/output capability is listed as Yes/Yes. The device supports a maximum frequency of 100MHz, operates from a 2.25V to 3.63V supply, and is specified for a -40°C to 85°C operating temperature range. It is supplied in an 8-WFDFN Exposed Pad package, with the supplier device package identified as 8-TDFN (1.4x1.6), and uses surface-mount installation. The listed lifecycle status is Last Time Buy.
Key Features
- Main purpose is PCI Express (PCIe).
- Clock input and clock output with a 1:2 input-to-output ratio.
- Differential input and differential output are listed as Yes/Yes.
- Maximum frequency is 100MHz.
- Supply voltage range is 2.25V to 3.63V.
- Operating temperature range is -40°C to 85°C.
- Surface-mount package is 8-WFDFN Exposed Pad, supplier device package 8-TDFN (1.4x1.6).
Applications
- PCIe add-in cards using a clock buffer in the PCIe timing path.
- PCIe storage controller boards using a 100MHz PCIe clock.
- PCIe network adapter boards with surface-mount timing components.
- PCIe host interface boards using a differential clock path.
Design & Procurement Notes
Designers should verify the 8-TDFN (1.4x1.6) exposed-pad footprint and surface-mount assembly process, and confirm that the 2.25V to 3.63V supply and -40°C to 85°C operating temperature range match the board environment. The 100MHz maximum frequency and 1:2 input-to-output ratio should be checked against the PCIe clock tree requirements. Because the product status is Last Time Buy, procurement planning should account for the listed lifecycle status and future supply needs. The data lists PLL as No and
