FZ800R33KF2C
3300V 800A single IGBT module with high power density for medium voltage applications
Quick Answer: FZ800R33KF2C is an Infineon / EUPEC high-power IGBT module designed for demanding industrial power conversion and medium-voltage applications.
- Manufacturer
- Infineon Technologies
- Product Category
- IGBT Modules
- Package
- MODULE
- Stock
- 150 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Infineon Technologies |
|---|---|
| Product Category | IGBT Modules |
| Applications | Medium Voltage Drives, Railway Traction, Industrial Converters |
| Baseplate Material | AlSiC |
| Collector Current (IC) | 800A |
| Collector-Emitter Saturation Voltage (VCEsat) | 3.4V Typ. |
| Configuration | Single IGBT |
| Continuous Collector Current | 1300A |
| Gate-Emitter Voltage (VGES) | ±20V |
| Isolation Voltage | High Voltage Insulation Design |
| Mounting Type | Screw Mount |
| Operating Junction Temperature | -40°C to +125°C |
| Package Type | IHM Module |
| Power Dissipation (Ptot) | 9600W |
| RoHS Compliance | No / Check Manufacturer Status |
| Short Circuit Capability | Yes |
| Switching Performance | High Power Switching |
| Technology | Silicon IGBT |
| Technology Generation | IGBT2 |
| Voltage Rating (VCES) | 3300V |
| Datasheet | Request Datasheet |
Procurement Snapshot
Key supply and purchasing information for FZ800R33KF2C.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for FZ800R33KF2C
Product Overview
FZ800R33KF2C is an Infineon / EUPEC high-power IGBT module designed for demanding industrial power conversion and medium-voltage applications. This module features a 3300V voltage rating and 800A current capability, utilizing advanced IGBT technology for high-efficiency switching and reliable operation. With a robust press-pack style construction, high power density and excellent thermal performance, FZ800R33KF2C is suitable for traction systems, HVDC converters, industrial drives, renewable energy converters and large-scale power electronics equipment.
Key Features
Manufacturer: Infineon Technologies / EUPEC
Part Number: FZ800R33KF2C
Product Type: High Power IGBT Module
IGBT Technology: High Voltage IGBT
Collector-Emitter Voltage (VCES): 3300V
Collector Current (IC): 800A
Configuration: Dual IGBT module
Integrated Components: IGBT switches and freewheeling diodes
Emitter Controlled / Field Stop IGBT Technology
High Short Circuit Capability
Low Switching Losses
High Blocking Voltage Capability
Maximum Junction Temperature: 150°C
Isolation Voltage: High voltage insulated package design
Gate-Emitter Voltage: ±20V
Cooling Method: Forced air or liquid cooling system
Mounting Type: Screw mounting
Package Type: High-power IGBT module housing
Technology Platform: Suitable for 2-level and multilevel converter topologies
Driver Compatibility: Compatible with SCALE™-2 plug-and-play gate drivers such as 1SP0635 series
Applications: Traction systems, HVDC, FACTS, industrial converters and wind power systems
Design Feature: High reliability, long service life and optimized power density
Operating Temperature Range: Industrial power semiconductor temperature range
Package Technology: Electrically insulated power module construction
Features: High voltage capability, high current handling, low losses and excellent thermal performance
Typical Applications: Railway traction, medium-voltage drives, renewable energy converters and large industrial power systems
Datasheet: FZ800R33KF2C datasheet PDF available for technical verification before production use.
Applications
FZ800R33KF2C is designed for high-power switching systems requiring excellent reliability, high voltage endurance and efficient energy conversion. Typical applications include railway traction converters, HVDC transmission systems, flexible AC transmission systems (FACTS), medium-voltage industrial drives, wind power converters, medical power systems and research power equipment.
