V110C5E75BL
DC DC CONVERTER 5V 75W
- 產品分類
- DC/DC 轉換器
- 封裝
- Quarter Brick
- 庫存
- 1,478 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Vicor Corporation |
|---|---|
| 產品分類 | DC/DC 轉換器 |
| Applications | ITE (Commercial) |
| Current - Output (Max) | 15A |
| Efficiency | 83.6% |
| Features | OVP, UVLO |
| Min Qty | 1 |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature | -10°C ~ 100°C |
| Package | Bulk |
| Power (Watts) | 75 W |
| Product status | Active |
| Series | MICRO (75W) |
| Size / Dimension | 2.28" L x 1.45" W x 0.62" H (57.9mm x 36.8mm x 15.7mm) |
| Type | Isolated Module |
| Voltage - Input (Max) | 154V |
| Voltage - Input (Min) | 66V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 5V |
| 資料表 | 查看資料表PDF |
採購概覽
V110C5E75BL 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
V110C5E75BL 詳細描述
Product Overview
The Vicor Corporation V110C5E75BL is a board-mount isolated module DC-DC converter that provides a single 5V output from a 66V to 154V input. The quarter-brick converter is rated for 75W and can deliver up to 15A on the output. It includes overvoltage protection and undervoltage lockout, and it specifies 3kV isolation. This component is suitable for commercial information technology equipment power conversion where galvanic isolation, a 5V rail, and through-hole mounting are required.
Key Features
- Single 5V isolated output for board-level DC-DC conversion
- Input voltage range of 66V to 154V
- Output current capability up to 15A
- Rated output power of 75W
- 3kV voltage isolation rating
- Overvoltage protection and undervoltage lockout features
- Operating temperature range from -10°C to 100°C
- Quarter-brick package with through-hole mounting
- 2.28" L x 1.45" W x 0.62" H (57.9mm x 36.8mm x 15.7mm) size
Applications
- Commercial information technology equipment requiring an isolated 5V rail from a higher input bus
- Board-level power distribution in systems using a 66V to 154V input supply
- Isolated power conversion for commercial equipment with through-hole quarter-brick mounting
Design & Procurement Notes
When selecting the V110C5E75BL, confirm that the system input remains within 66V to 154V and that the 5V output load does not exceed 15A or 75W. The 83.6% efficiency value indicates that losses should be considered in thermal design, especially near the upper end of the -10°C to 100°C operating range. The 3kV isolation rating supports galvanic separation between input and output, but the final PCB layout and mounting provisions must still be verified against the quarter-brick dimensions and through-hole footprint. OVP and UVLO are device features, not a substitute for system-level protection requirements.
