BCM380P475M1K2A30

Product Overview

The Vicor Corporation BCM380P475M1K2A30 is a single-output, isolated DC-DC converter module for board-level power conversion from a 260 V to 410 V input to a 47.5 V output. The module provides up to 25.7 A and a 1221 W output power capability, with an isolation voltage of 4.242 kV. It uses a through-hole 9-DIP module package measuring 63.3 mm by 22.8 mm by 7.3 mm. The device operates from -55°C to 125°C and has an efficiency of 97.7%. Adjustable output capability supports board-level rail configuration within the specified operating envelope.

Key Features

• Single isolated output delivering 47.5 V at up to 25.7 A from a 260 V to 410 V input range.
• 1221 W output power capability in a 9-DIP through-hole module.
• 4.242 kV isolation voltage.
• Adjustable output feature for board-level output configuration.
• Operating temperature range of -55°C to 125°C.
• Efficiency of 97.7%.
• Module dimensions of 63.3 mm by 22.8 mm by 7.3 mm.
• CE, cTUVus, and cURus agency approvals.

Applications

• Commercial information technology equipment power supplies
• Board-mounted systems using a 260 V to 410 V DC input
• Equipment using a 47.5 V isolated output rail

Design & Procurement Notes

Designers should account for the 260 V to 410 V input window, 47.5 V output, 25.7 A maximum output current, and 1221 W power rating when defining the DC bus, output connections, and thermal budget. The through-hole 9-DIP module package and 63.3 mm by 22.8 mm by 7.3 mm dimensions influence PCB layout, keepout areas, and mechanical clearance. The 4.242 kV isolation voltage and CE, cTUVus, and cURus approvals are relevant to safety-related layout and system documentation, while the -55°C to 125°C operating range should be checked against board-level ambient conditions. The adjustable output feature should be configured within the module's specified limits.
