TLP165J
TLP165J is a Toshiba photo-triac optocoupler featuring high isolation voltage and AC load control capability for solid-state relay and industrial applications
- 產品分類
- 光耦合器/光電耦合器
- 封裝
- SOP-4
- 庫存
- 1,500 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Toshiba Semiconductor and Storage |
|---|---|
| 產品分類 | 光耦合器/光電耦合器 |
| Applications | Solid State Relays, AC Output Modules, Programmable Controllers, Industrial Control Equipment |
| Features | Compact Package, High Voltage Isolation, Low Trigger Current, Reliable AC Switching Performance |
| Forward Current (IF) | 50mA Maximum |
| Forward Voltage (VF) | 1.3V Typical |
| Input Type | GaAs Infrared LED |
| Insulation Type | Reinforced Isolation |
| Isolation Voltage | 2500Vrms Minimum |
| Mounting Style | Surface Mount Technology (SMD) |
| Number of Channels | 1 Channel |
| On-State Current (IT) | 70mA Maximum |
| Operating Temperature Range | -40°C to +100°C |
| Optocoupler Type | Photo-Triac Output |
| Output Type | Photo-Triac |
| Package Type | Mini Flat SOP-4 |
| Peak Off-State Voltage (VDRM) | 600V Minimum |
| Reverse Voltage (VR) | 5V Maximum |
| Safety Standard | UL1577 Recognized |
| Storage Temperature Range | -55°C to +125°C |
| Trigger LED Current (IFT) | 10mA Maximum |
| VDE Approval | EN 60747-5-2 Compliant (Option Type) |
| Weight | 0.09g Typical |
| 資料表 | 索取數據表 |
採購概覽
TLP165J 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
TLP165J 詳細描述
Product Overview
TLP165J is a Toshiba mini-flat photocoupler featuring a GaAs infrared LED optically coupled with a photo-triac output. Designed for AC signal switching and electrical isolation applications, this device provides a 600V peak off-state voltage rating, 2500Vrms isolation voltage and reliable triac drive performance. With a compact surface-mount package and high noise immunity, it is suitable for programmable controllers, AC output modules, solid-state relays and industrial control equipment.
Key Features
Manufacturer: Toshiba Electronic Devices & Storage Corporation
Part Number: TLP165J
Product Type: Photocoupler / Optocoupler
Output Type: Photo-Triac Output
Input Device: GaAs Infrared LED
Number of Channels: 1 Channel
Peak Off-State Voltage (VDRM): 600V min.
On-State Current (IT): 70mA max.
Trigger LED Current (IFT): 10mA max.
Isolation Voltage: 2500Vrms min.
Forward Current (IF): 50mA max.
Forward Voltage: Approx. 1.15V typical
Output Configuration: Random-phase photo-triac
Package Type: Mini Flat Coupler
Mounting Type: Surface Mount Device (SMD)
Package Configuration: 4-pin SOP package
Switching Function: Triac drive for AC load control
Safety Certification: UL1577 recognized
Insulation Rating: VDE EN60747-5-2 option available
Operating Temperature Range: -55°C to +100°C
Features: High isolation, compact design, reliable AC switching and noise-resistant operation
Typical Applications: AC output modules, solid-state relays, PLC systems and industrial automation equipment
Datasheet: TLP165J datasheet PDF available for technical verification before production use.
Applications
TLP165J is designed for isolated AC switching applications requiring reliable triac control and protection between input and output circuits. Typical applications include programmable logic controllers (PLC), AC output modules, industrial automation equipment, solid-state relays, lighting control systems and power control interfaces.Quality & Sourcing
Antrex Electronics can support TLP165J sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, customers can provide quantity requirements, delivery schedules, application details and technical specifications for faster quotation support.
For quality assurance, Antrex Electronics can assist with product photos, marking verification, visual inspection and third-party testing services when required. OEM manufacturers, industrial equipment suppliers, repair centers and electronic component buyers are welcome to submit BOM lists or hard-to-find optoelectronic component requirements for sourcing assistance.
