1-1462037-4

Product Overview

1-1462037-4 is a compact IM Series signal relay from TE Connectivity / Axicom designed for telecommunications, control, instrumentation and signal-switching applications. The relay features a 5VDC coil, DPDT (2 Form C) contact configuration and a maximum switching current of 2A. Its non-latching construction, low 140mW coil power and surface-mount gull-wing terminals make it suitable for space-constrained PCB designs. With switching ratings up to 250VAC or 220VDC and reliable mechanical performance, 1-1462037-4 provides efficient signal switching for communication, industrial and electronic control equipment.

Key Features

• Manufacturer: TE Connectivity / Axicom

• Part Number: 1-1462037-4

• Manufacturer Description: IM03GR=IM Relay 140mW 5V

• Product Type: Signal Relay

• Product Series: IM Series

• Relay Construction: Non-Latching

• Contact Configuration: DPDT (2 Form C)

• Nominal Coil Voltage: 5VDC

• Coil Resistance: 178Ω

• Coil Current: Approximately 28.1mA

• Coil Power: 140mW

• Maximum Switching Current: 2A

• Maximum AC Switching Voltage: 250VAC

• Maximum DC Switching Voltage: 220VDC

• Maximum Switching Power: 62.5VA / 60W

• Maximum Contact Resistance: 50mΩ

• Contact Material: Palladium Ruthenium / Gold

• Operate Time: Approximately 3ms

• Release Time: Approximately 3ms

• Mounting Type: Surface Mount

• Termination Style: Gull Wing

• Number of Terminals: 8

• Operating Temperature Range: -40°C to +85°C

• Approximate Dimensions: 10 × 7.5 × 5.65mm

• Compliance: RoHS Compliant

Applications

1-1462037-4 is suitable for compact electronic systems requiring reliable low-power signal switching. Typical applications include telecommunications equipment, communication interfaces, industrial control systems, measurement and test equipment, security systems, instrumentation, office electronics and other PCB-based signal switching circuits.

Quality & Sourcing

Antrex Electronics can support 1-1462037-4 sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, marking verification, visual inspection and third-party testing support when required. OEMs, EMS providers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find relay requirements for sourcing assistance.
