1218266-1
CONN D-SUB PIN 18AWG CRIMP GOLD
- 產品分類
- D-Sub與D型連接器
- 封裝
- -
- 庫存
- 17,777 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | TE Connectivity Aerospace, Defense and Marine |
|---|---|
| 產品分類 | D-Sub與D型連接器 |
| Min Qty | 1 |
| Package | Bulk |
| Product status | Active |
| Series | AMPLIMITE 109 |
| 資料表 | 查看資料表PDF |
採購概覽
1218266-1 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
1218266-1 詳細描述
Product Overview
The TE Connectivity Aerospace, Defense and Marine 1218266-1 is a male D-sub pin contact in the AMPLIMITE 109 series. It is intended for signal connections and uses a crimp termination for 18 AWG conductors. The machined contact is made from copper alloy and finished with gold plating measuring 30.0µin (0.76µm). Its contact size is 20.
Key Features
- Male pin D-sub contact for signal circuits
- Machined copper alloy contact with gold finish of 30.0µin (0.76µm)
- Crimp termination suited to 18 AWG wire
- Contact size 20 within the AMPLIMITE 109 series
Applications
- Panel-mounted signal wiring in equipment using D-sub connector interfaces
- Cable harnesses that terminate 18 AWG signal conductors with crimped male pins
- Service work on D-sub signal connections requiring size 20 male pin contacts
Design & Procurement Notes
When specifying 1218266-1, confirm that the connector cavity accepts size 20 male contacts and that the mating interface requires a pin rather than a socket. The crimp termination should be matched to 18 AWG wire and appropriate crimping process. Verify that the AMPLIMITE 109 series and signal contact type align with the mechanical and electrical architecture of the D-sub connection. The gold finish thickness of 30.0µin (0.76µm) can be reviewed where contact finish consistency is part of the connector selection.
