料號

ATB2012-50011-T000

BALUN 40MHZ-860MHZ 50/50 0805

製造商: TDK Corporation
產品分類: 射頻巴倫（平衡/不平衡轉換器）
封裝: 0805 (2012 Metric)
庫存: 70,000 件
供貨狀態: 當前數量需確認。

查詢價格及供貨查看資料表PDF

詢價內容包括： 價格庫存確認生產批次交期

可按要求提供產品實拍及檢測支援。

產品屬性

製造商	TDK Corporation
產品分類	射頻巴倫（平衡/不平衡轉換器）
Frequency Range	40MHz ~ 860MHz
Impedance - Unbalanced/Balanced	50 / 50Ohm
ion Loss (Max)	2.5dB
Min Qty	1
Mounting Type	Surface Mount
Package	Tape & Reel (TR),Cut Tape (CT)
Product status	Active
Series	ATB
資料表	查看資料表PDF

採購資訊

採購概覽

ATB2012-50011-T000 的主要供貨及採購資訊。

查詢價格及供貨

料號 ATB2012-50011-T000

供貨狀態 列示庫存 70,000 pcs 當前數量需確認。

包裝與狀況 可確認包裝資訊 可按要求核對原廠包裝、標籤及包裝狀況。

生產批次與批號 可提供核實 可按要求核對生產批次、批號及標籤資料。

檢驗支援 檢驗及測試支援 可安排外觀檢查、X-ray 或其他測試。

採購支援 批量及缺貨採購 支援 OEM、EMS、難找料及長期供應需求。

採購能力

為何選擇 Antrex Electronics？

為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。

獨立分銷支援

支援短缺、停產及難找電子元器件的生產與採購需求。

可追溯性審查

可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。

檢驗與測試

如有需要，可安排外觀檢查、X-ray 及第三方測試支援。

全球採購支援

支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。

品質與採購

資質與驗證支援

為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。

ISO 9001 品質管理

ESD Control 元器件處理

ERAI 行業採購支援

Traceability 標籤、批號及文件審查

測試支援 X-ray 及第三方測試

ATB2012-50011-T000 詳細描述

Product Overview

ATB2012-50011-T000 integrates the balanced/unbalanced transformation required in 40 MHz to 860 MHz signal paths. The 1:1 relationship connects the 50 Ω unbalanced / 50 Ω balanced ports while preserving the balance, loss and package characteristics published for this exact TDK ordering code. Confirmed selection limits include insertion loss of 2.5 dB maximum.

The broad VHF/UHF response targets television and mobile tuner signal paths that require a balanced port without changing the nominal impedance. The winding ratio, port impedance, package dimensions and lifecycle status should all be checked during replacement review; related ATB or HHM products may have different balanced impedances or center-tap arrangements.

Key Features

Manufacturer: TDK
Part Number: ATB2012-50011-T000
Product Category: RF Balun / Integrated Matching Network
Device Type: wound SMD 1:1 balun transformer
Frequency Range: 40 MHz to 860 MHz
System / Port Impedance: 50 Ω unbalanced / 50 Ω balanced
Impedance Ratio: 1:1
Insertion Loss: 2.5 dB maximum
Package / Case: 2.0 × 1.2 × 1.2 mm ATB2012 package
Mounting Type: Surface mount
Operating Temperature: -40°C to +85°C
Technology: wound SMD or multilayer RF transformer construction

Applications

DVB-T/H and ISDB-T tuner modules
VHF/UHF receiver signal paths
50 Ω single-ended-to-balanced conversion

Quality & Sourcing

Antrex Electronics can support sourcing of ATB2012-50011-T000 for production, repair and shortage requirements. Incoming verification can include manufacturer marking, package dimensions, frequency and impedance review, date-code checks and third-party inspection when requested. For obsolete or NRND parts, the exact ordering suffix should be maintained until an engineering-approved alternative is qualified.

取得報價上傳 BOM
