MPX10GP

Product Overview

MPX10GP is a NXP Semiconductors silicon piezoresistive pressure sensor designed for low-cost pressure measurement applications. The device provides an accurate and linear analog voltage output proportional to the applied pressure, with a 10kPa pressure range and uncompensated sensor design. It features a single-element strain gauge sensing structure, excellent sensitivity, low power consumption and reliable performance, making it suitable for applications requiring external temperature compensation and signal conditioning circuits.

Key Features

• Manufacturer: NXP Semiconductors

• Part Number: MPX10GP

• Full / Related Part Number: MPX10GP

• Device Type: Piezoresistive pressure sensor

• Product Category: Board mount pressure sensor

• Sensor Technology: Silicon strain gauge pressure sensing technology

• Pressure Type: Gauge pressure sensor

• Operating Pressure Range: 0kPa to 10kPa

• Pressure Range: 10kPa

• Output Type: Analog voltage output

• Supply Voltage: 1V to 6VDC

• Typical Supply Voltage: 3VDC

• Supply Current: Approximately 6mA

• Sensitivity: Approximately 3.5mV/kPa

• Accuracy: Approximately ±0.5% full scale

• Compensation: Uncompensated sensor requiring external compensation circuit

• Package Type: 344B-01 unibody package

• Mounting Type: Through-hole mounting

• Operating Temperature: -40°C to +125°C

• Typical Use: Air pressure monitoring, industrial sensing, medical equipment and consumer electronics

• Ordering / Packaging Note: MPX10GP buyers should verify package type, pressure range, port configuration, date code and manufacturer documentation before production use.

Applications

MPX10GP is suitable for pressure measurement applications including air flow monitoring, pneumatic control systems, medical equipment, environmental monitoring devices, industrial automation systems, consumer electronics and embedded sensor modules. Its compact design, analog output and reliable silicon sensing technology make it suitable for applications requiring economical and flexible pressure detection solutions.

Quality & Sourcing

Antrex Electronics can support MPX10GP sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, label review, visual inspection and third-party testing support when required. OEMs, EMS providers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find part requests for sourcing assistance.
