LD6836CX4/22P,315
IC REG LINEAR 2.2V 300MA 4WLCSP
- 製造商
- NXP USA Inc.
- 產品分類
- 電壓穩壓器與電壓控制器
- 封裝
- 4-XFBGA, WLCSP
- 庫存
- 18,000 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | NXP USA Inc. |
|---|---|
| 產品分類 | 電壓穩壓器與電壓控制器 |
| Control Features | Enable |
| Current - Output | 300mA |
| Current - Quiescent (Iq) | 100 µA |
| Current - Supply (Max) | 250 µA |
| Min Qty | 2664 |
| Mounting Type | Surface Mount |
| Number of Regulators | 1 |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Output Type | Fixed |
| Package | Bulk |
| Product status | Obsolete |
| Protection Features | Over Current, Over Temperature |
| PSRR | 55dB (1kHz) |
| Supplier Device Package | 4-WLCSP (0.76x0.76) |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 2.2V |
| Voltage Dropout (Max) | 0.16V @ 300mA |
| 資料表 | 查看資料表PDF |
採購概覽
LD6836CX4/22P,315 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
LD6836CX4/22P,315 詳細描述
Product Overview
The LD6836CX4/22P,315 from NXP USA Inc. is a linear voltage regulator IC that provides a positive fixed 2.2 V output from a single regulator channel. It is housed in a 4-WLCSP (0.76x0.76) surface-mount package for compact power-management layouts. The device accepts input voltages up to 5.5 V and can deliver up to 300 mA, with a maximum dropout voltage of 0.16 V at 300 mA. Its quiescent current is 100 µA, and the maximum supply current is 250 µA, supporting low-power operation while maintaining a fixed output.
Key Features
- Positive fixed-output linear regulator with one regulator channel and a 2.2 V fixed output voltage.
- Maximum input voltage of 5.5 V and maximum output current of 300 mA.
- Maximum dropout voltage of 0.16 V at 300 mA.
- Quiescent current of 100 µA and maximum supply current of 250 µA.
- Enable control feature with over-current and over-temperature protection.
- PSRR of 55 dB at 1 kHz.
- 4-XFBGA, WLCSP surface-mount package, 4-WLCSP (0.76x0.76).
Applications
- Fixed 2.2 V supply rail for low-power digital or mixed-signal circuits within the stated input, current, and temperature limits.
- Noise-sensitive circuits where the 55 dB PSRR at 1 kHz is applicable.
- Compact embedded boards using a single fixed-output LDO in a 4-WLCSP footprint.
Design & Procurement Notes
Design considerations include verifying that the input voltage remains within the 5.5 V maximum while still exceeding the 2.2 V output plus dropout requirement under load. The 0.16 V maximum dropout at 300 mA should be used when evaluating minimum headroom, and the 300 mA output limit should be compared with the load current. The enable control feature can be used to control regulator operation, while over-current and over-temperature protection should be considered within the -40°C to 85°C operating range. The 4-WLCSP (0.76x0.76) surface-mount package requires appropriate PCB pad layout and assembly planning for the selected load current. The 55 dB PSRR at 1 kHz should be evaluated against noise-sensitive loads. For procurement, confirm the exact part number LD6836CX4/22P,315 and package code 4-WLCSP (0.76x0.76) because the small surface-mount format affects assembly and footprint.
