NJM78L05UA-TE1
IC REG LINEAR 5V 100MA SOT89
- 產品分類
- 電壓穩壓器與電壓控制器
- 封裝
- TO-243AA
- 庫存
- 79,048 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Nisshinbo Micro Devices Inc. |
|---|---|
| 產品分類 | 電壓穩壓器與電壓控制器 |
| Current - Output | 100mA |
| Current - Quiescent (Iq) | 6 mA |
| Min Qty | 1 |
| Mounting Type | Surface Mount |
| Number of Regulators | 1 |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Output Type | Fixed |
| Package | Tape & Reel (TR),Cut Tape (CT) |
| Product status | Active |
| Protection Features | Over Temperature, Short Circuit |
| PSRR | 69dB (120Hz) |
| Supplier Device Package | SOT-89 |
| Voltage - Input (Max) | 30V |
| Voltage - Output (Min/Fixed) | 5V |
| 資料表 | 查看資料表PDF |
採購概覽
NJM78L05UA-TE1 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
NJM78L05UA-TE1 詳細描述
Product Overview
The NJM78L05UA-TE1 from Nisshinbo Micro Devices Inc. is a positive, fixed-output linear voltage regulator for surface-mount board designs. It provides one 5V output at up to 100mA and has a maximum input voltage of 30V. The device is supplied in a TO-243AA package, with a supplier device package of SOT-89, and is specified for operation from -40°C to 85°C. It includes over-temperature and short-circuit protection, with 6 mA quiescent current and 69dB PSRR at 120Hz.
Key Features
- Positive fixed-output regulator with one 5V output and 100mA current capability.
- Maximum input voltage: 30V.
- Quiescent current: 6 mA.
- PSRR: 69dB at 120Hz.
- Includes over-temperature and short-circuit protection.
- Surface-mount TO-243AA package, supplier device package SOT-89.
- Operating temperature range: -40°C to 85°C.
Applications
- Regulating a 5V rail for low-current logic, sensor, or analog circuitry on a printed circuit board.
- Providing a compact surface-mount fixed voltage source in space-constrained general electronics assemblies.
- Maintaining a 5V supply for peripheral circuits where a 100mA load current limit is appropriate.
Design & Procurement Notes
For design use, the NJM78L05UA-TE1 is a fixed 5V regulator, so output voltage cannot be adjusted. The 100mA output rating and 30V maximum input define the usable load and input supply limits. The 6 mA quiescent current should be considered in low-power circuits. The SOT-89, TO-243AA surface-mount package supports compact board layouts, while the -40°C to 85°C operating range and over-temperature and short-circuit protection are relevant to thermal and fault planning. The listed Active product status is useful for procurement review.
NJM78L05UA-TE1 採購與供應支援
詢價支援NJM78L05UA-TE1 是由 Nisshinbo Micro Devices Inc. 製造的電壓穩壓器與電壓控制器 產品。Antrex Electronics 可協助確認目前庫存、價格、生產批次、交期及採購需求。
產品審核說明
NJM78L05UA-TE1 被歸類為 電壓穩壓器與電壓控制器 產品，製造商為 Nisshinbo Micro Devices Inc.。買家下單前應確認完整訂購型號、封裝、數量及專案需求。
詢價核對項目
- 目前庫存、價格及交期
- 生產批次、封裝類型及標籤照片
- 卷帶、托盤、管裝或剪帶包裝狀況
- 目標價格、需求數量及 BOM 採購要求
