LDB151G9AAD1A031
RF-D
- 產品分類
- 射頻巴倫（平衡/不平衡轉換器）
- 封裝
- -
- 庫存
- 703 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Murata Electronics |
|---|---|
| 產品分類 | 射頻巴倫（平衡/不平衡轉換器） |
| Min Qty | 10000 |
| Package | Tape & Reel (TR) |
| Product status | Active |
| 資料表 | 索取數據表 |
採購概覽
LDB151G9AAD1A031 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
LDB151G9AAD1A031 詳細描述
Product Overview
LDB151G9AAD1A031 is a Murata Electronics ultra-miniature multilayer LC balun specified for 1.695 GHz to 2.2 GHz. The unity-ratio network preserves the nominal 50 Ω unbalanced / 50 Ω balanced relationship while converting between single-ended and balanced circuitry. Confirmed selection data includes insertion-loss performance of 1.3 dB maximum at 25°C; 1.4 dB over the stated temperature range, return loss of 8.54 dB minimum.
The range supports Cellular and broadband wireless differential RFIC ports. The exact balanced impedance is especially important because nearby ordering codes may cover the same band while presenting 50 Ω, 75 Ω, 100 Ω, 150 Ω or 200 Ω differential ports. The recorded lifecycle state is Exact compact RFIC-interface code, so the part is principally relevant to legacy production, repair and shortage sourcing.
Key Features
- Manufacturer: Murata Electronics
- Part Number: LDB151G9AAD1A031
- Product Category: RF Balun / RF Transformer
- Device Type: ultra-miniature multilayer LC balun
- Frequency Range: 1.695 GHz to 2.2 GHz
- System / Port Impedance: 50 Ω unbalanced / 50 Ω balanced
- Impedance / Matching Relationship: 1:1
- Insertion Loss: 1.3 dB maximum at 25°C; 1.4 dB over the stated temperature range
- Return Loss: 8.54 dB minimum
- Package / Case: 0402 (1005 metric) multilayer package
- Mounting Type: Surface mount
- Operating Temperature: -40°C to +85°C
- Lifecycle Status: Exact compact RFIC-interface code
- Target Application: Cellular and broadband wireless differential RFIC ports
Applications
- Cellular and broadband wireless differential RFIC ports
- Single-ended-to-balanced receiver, transmitter, mixer and amplifier interfaces
- Cellular, telemetry, instrumentation and broadband communication equipment
Quality & Sourcing
Antrex Electronics can support sourcing of LDB151G9AAD1A031 for production, repair and shortage requirements. Incoming verification can compare the exact manufacturer marking, ordering suffix, package dimensions, frequency range, single-ended and balanced impedances, insertion-loss limits and lifecycle status. For obsolete or NRND devices, Antrex Electronics can also coordinate BOM sourcing and third-party inspection before shipment, while alternative parts should remain subject to engineering approval for PCB footprint, impedance and RF performance.
