PS12014-A
Intelligent 3-phase IGBT power module for 0.75kW, 400VAC motor inverter applications
- 產品分類
- 功率驅動模組
- 封裝
- MODULE
- 庫存
- 500 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Mitsubishi Electric |
|---|---|
| 產品分類 | 功率驅動模組 |
| Application Voltage Class | AC 400 V |
| Bootstrap Supply Circuit | Integrated |
| Current Feedback | 3-Phase Analog Output Current Feedback |
| Current-Limit Warning Output | Supported |
| Dynamic Brake Circuit | Integrated |
| Fault Output Signaling | Supported |
| IGBT Generation | 3rd Generation |
| Input Interface | 5 V CMOS / TTL Compatible |
| Input Type | Schmitt Trigger |
| Module Type | Flat-Base Insulated Type |
| N-Side Drive Circuit | Integrated |
| Over-Temperature Protection | Integrated |
| Over-Voltage Protection | Integrated |
| Overload Duration | 1 Minute |
| Overload Output Current | 5.1 A RMS |
| P-Side Drive Circuit | Integrated |
| Power Device | 3-phase IGBT inverter bridge |
| Product Type | Application Specific Intelligent Power Module |
| Rated Motor Output | 0.75 kW |
| Rated Output Current | 3.4 A RMS |
| Short-Circuit Protection | Integrated |
| Typical Application | 3-Phase Motor Inverters |
| Under-Voltage Protection | Integrated |
| 資料表 | 索取數據表 |
採購概覽
PS12014-A 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
PS12014-A 詳細描述
Product Overview
PS12014-A is a Mitsubishi Electric intelligent power module (IPM) designed for compact inverter and motor control applications. This module integrates high-voltage IGBT power devices, free-wheeling diodes and built-in gate drive protection circuits into a single package, providing efficient switching performance, simplified circuit design and reliable operation. With integrated protection functions and rugged industrial construction, PS12014-A is suitable for motor drives, industrial automation equipment and power conversion systems.
Key Features
Manufacturer: Mitsubishi Electric
Part Number: PS12014-A
Product Type: Intelligent Power Module (IPM)
Semiconductor Technology: IGBT power module
Module Configuration: Three-phase inverter bridge
Integrated Components: IGBT chips, free-wheeling diodes and driver circuits
Gate Drive Circuit: Built-in gate driver for simplified design
Protection Functions: Short-circuit, overcurrent and undervoltage protection
Switching Performance: Optimized for efficient inverter operation
Voltage Capability: High-voltage switching application support
Current Capability: Designed for compact motor drive systems
Isolation Performance: High electrical isolation capability
Package Type: Compact IPM power module package
Mounting Type: Screw mounting with heat sink installation
Thermal Performance: Optimized heat dissipation design
Operating Temperature: Industrial temperature range support
Application Category: Motor control and power conversion
Reliability Features: Integrated protection and rugged construction
Application Devices: Inverters, AC drives and industrial equipment
Ordering Note: Buyers should verify exact voltage/current ratings, package dimensions and latest Mitsubishi Electric datasheet before production use.
Applications
PS12014-A is designed for inverter systems requiring compact, efficient and reliable power switching performance. Typical applications include industrial motor drives, servo systems, HVAC controllers, pumps, fans, factory automation equipment, robotics and general-purpose inverter platforms.
Quality & Sourcing
Antrex Electronics provides sourcing support for PS12014-A including stock verification, quotation service, package confirmation, date code review and shipment coordination. Customers can provide quantity requirements, delivery schedules and application details for efficient purchasing support.
For quality assurance, Antrex Electronics can assist with product marking verification, visual inspection and third-party testing services when required. Industrial manufacturers, automation suppliers and electronic component buyers are welcome to submit BOM lists or hard-to-find power module requirements for sourcing assistance.
