Z7550-FFNM+
1:1.5 C&W XFMR, DC - 2300 MHZ
- 製造商
- Mini-Circuits
- 產品分類
- 射頻巴倫（平衡/不平衡轉換器）
- 封裝
- F-Type In-Line Module
- 庫存
- 40 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Mini-Circuits |
|---|---|
| 產品分類 | 射頻巴倫（平衡/不平衡轉換器） |
| Frequency Range | 0Hz ~ 2.3GHz |
| ion Loss (Max) | 1.2dB |
| Min Qty | 1 |
| Mounting Type | Chassis Mount |
| Package | Tray |
| Product status | Active |
| 資料表 | 查看資料表PDF |
採購概覽
Z7550-FFNM+ 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
Z7550-FFNM+ 詳細描述
Product Overview
Z7550-FFNM+ is a Mini-Circuits connectorized 50 Ω-to-75 Ω matching transformer specified for DC to 2.3 GHz. This module performs broadband impedance matching between 50 Ω and 75 Ω systems without requiring a PCB-mounted transformer.
Its DC-passing response and 2.3 GHz upper limit suit laboratory setups, CATV interfaces and mixed-impedance RF equipment. The FFNM connector arrangement identifies the exact in-line mechanical interface and should be checked separately from the SMA-equipped FFSF version.
Key Features
- Manufacturer: Mini-Circuits
- Part Number: Z7550-FFNM+
- Product Category: RF Balun / RF Transformer
- Device Type: connectorized 50 Ω-to-75 Ω matching transformer
- Frequency Range: DC to 2.3 GHz
- System / Port Impedance: 50 Ω / 75 Ω
- Impedance Ratio: 1:1.5
- Insertion Loss: 1.2 dB maximum listing value
- Package / Case: F-Type in-line connectorized module
- Mounting Type: Chassis / cable connected
Applications
- 50 Ω test equipment to 75 Ω CATV interfaces
- Broadband laboratory and production test setups
- Connectorized impedance matching through 2.3 GHz
Quality & Sourcing
Antrex Electronics can support sourcing of Z7550-FFNM+ for production, repair and shortage requirements. Incoming inspection should compare the exact ordering code, operating band, impedance relationship, package or connector configuration and any center-tap or suffix-specific mechanical details. Parts from the same transformer family may not be interchangeable when the ratio, port impedance, lead style or installed geometry changes.
