ISPLSI1048C-50LG
The ISPLSI1048C-50LG is a high-density in-system programmable logic device (CPLD) from Lattice Semiconductor, featuring 192 macrocells, 8,000 usable gates, and low-power CMOS technology for military, aerospace, and industrial digital logic applications.
- 封裝
- PGA
- 庫存
- 1,500 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Lattice Semiconductor Corporation |
|---|---|
| 產品分類 | Embedded Complex Logic (FPGA, CPLD) 評估板 |
| Applications | Aerospace Electronics, Military Systems, Industrial Control, Communications Equipment, Digital Logic Replacement |
| Architecture | In-System Programmable CPLD |
| Dedicated Clock Inputs | 4 |
| Dedicated Input Pins | 12 |
| Global Output Enables | 2 |
| Lifecycle Status | Discontinued |
| Maximum Operating Frequency (fMAX) | 50 MHz |
| Military SMD Number | 5962-9558701MXC (for /883 version) |
| Mounting Type | Through Hole |
| Number of I/O Pins | 96 I/O Pins |
| Number of Macrocells | 192 Macrocells |
| Operating Temperature Range | -55°C to +125°C (Military Version) |
| Package Pin Count | 133 Pins |
| Package Type | CPGA (Ceramic Pin Grid Array) |
| Power Consumption | Low Power (L-Series) |
| Product Type | Complex Programmable Logic Device (CPLD) |
| Programming Method | In-System Programmable (ISP) |
| Propagation Delay (tpd) | 22 ns typ. |
| Registers | 288 Registers |
| RoHS Status | Obsolete / Legacy Device |
| Series | ispLSI® 1000 Family |
| Supply Voltage | 4.5 V to 5.5 V |
| Technology | EEPROM-Based CMOS |
| Usable Gate Count | 8,000 Gates |
