IDT54FCT163TLB

Product Overview

IDT54FCT163TLB is a high-speed synchronous presettable 4-bit binary counter manufactured by Integrated Device Technology (IDT), now part of Renesas Electronics. The device is based on Fast CMOS TTL-compatible (FCT) technology and provides synchronous counting, parallel loading and reset functions. Designed for military and industrial applications, IDT54FCT163TLB offers high-speed operation, low power consumption and strong output drive capability, making it suitable for timing circuits, frequency dividers, programmable counters and digital control systems.

Key Features

• Manufacturer: Integrated Device Technology (IDT) / Renesas Electronics

• Part Number: IDT54FCT163TLB

• Device Type: Synchronous Presettable Binary Counter

• Product Category: Logic Integrated Circuit

• Logic Family: Fast CMOS TTL-Compatible (FCT)

• Counter Type: 4-Bit Synchronous Binary Counter

• Counting Mode: Modulo-16 Binary Counting

• Operating Voltage: 5V Supply Operation

• Supply Voltage Range: 4.75V to 5.25V

• Clock Trigger: Positive Edge Triggered

• Reset Function: Synchronous Reset Input

• Preset Function: Parallel Data Loading Capability

• Enable Inputs: Count Enable Parallel (CEP) and Count Enable Trickle (CET)

• Terminal Count Output: Available for Cascading Multiple Counters

• Input Leakage Current: ≤1µA Maximum

• Output Drive Capability: -15mA IOH / 48mA IOL

• Output Compatibility: TTL-Compatible CMOS Outputs

• Typical Propagation Delay: High-Speed CMOS Logic Performance

• Low Power CMOS Operation

• Meets JEDEC Standard 18 Requirements

• Military Temperature Range: -55°C to +125°C

• Package Type: 20-Pin Leadless Chip Carrier (LCC)

• Package Code: LC20

• Package Dimensions: Approximately 8.9mm × 8.9mm

• Mounting Type: Surface Mount / Ceramic Package

• Application Type: Digital Timing and Counting Control

• Typical Applications: Frequency Dividers, Programmable Counters, Digital Control Systems, Avionics Equipment and Military Electronics

• Product Status: Obsolete / Maintenance Component

• Ordering Note: Verify package type, speed grade, temperature rating and military qualification requirements before replacement use.
