HIN201CB
IC TRANSCEIVER FULL 2/2 16SOIC
- 產品分類
- 驅動器、接收器與收發器IC
- 封裝
- 16-SOIC (0.295", 7.50mm Width)
- 庫存
- 6,211 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Harris Corporation |
|---|---|
| 產品分類 | 驅動器、接收器與收發器IC |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Package | Bulk |
| Product status | Active |
| Voltage - Supply | 4.5V ~ 5.5V, 9V ~ 13.2V |
| 資料表 | 查看資料表PDF |
採購概覽
HIN201CB 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
HIN201CB 詳細描述
Product Overview
The HIN201CB from Harris Corporation is a surface-mount RS-232 transceiver housed in a 16-SOIC package. It provides two drivers and two receivers for full-duplex serial communication, with a specified data rate of 120kbps. The device supports supply ranges of 4.5V to 5.5V or 9V to 13.2V and includes a receiver hysteresis of 500 mV. Its 16-SOIC (0.295", 7.50mm width) package is intended for surface-mount assembly, while the 0°C to 70°C (TA) operating temperature range defines the ambient conditions for designs operating within the specified temperature range.
Key Features
- Manufacturer part number HIN201CB from Harris Corporation.
- RS-232 transceiver with 2 drivers and 2 receivers for full-duplex operation.
- Specified data rate of 120kbps.
- Receiver hysteresis of 500 mV.
- Operates from supply ranges of 4.5V to 5.5V or 9V to 13.2V.
- Surface-mount 16-SOIC package, 0.295" (7.50mm) width.
- Operating temperature range of 0°C to 70°C (TA).
Applications
- Host-to-peripheral RS-232 serial data exchange.
- Embedded control equipment using full-duplex two-channel serial interface paths.
- Point-to-point communication links operating within the specified 120kbps RS-232 data rate.
Design & Procurement Notes
When selecting the HIN201CB, confirm that the board power architecture can provide one of the two specified supply ranges, 4.5V to 5.5V or 9V to 13.2V, and that the serial link requires two transmit and two receive channels with full-duplex operation. The 120kbps data rate and 500 mV receiver hysteresis should be checked against the expected communication speed and input signal margins. Layout and mechanical planning should account for the surface-mount 16-SOIC package, 0.295" (7.50mm) width, and the 0°C to 70°C (TA) operating temperature range. For design documentation, specify the exact manufacturer part number HIN201CB to preserve the specified package, supply, and interface characteristics.
