CD74HCT7046AE
IC PHASE LOCK LOOP 16DIP
- 產品分類
- 時脈產生器、鎖相迴路與頻率合成器
- 封裝
- 16-DIP (0.300", 7.62mm)
- 庫存
- 12,333 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Harris Corporation |
|---|---|
| 產品分類 | 時脈產生器、鎖相迴路與頻率合成器 |
| Differential - Input:Output | No/No |
| Divider/Multiplier | No/No |
| Frequency - Max | 38MHz |
| Input | CMOS |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature | -55°C ~ 125°C |
| Output | CMOS |
| Package | Tube |
| PLL | Yes |
| Product status | Obsolete |
| Ratio - Input:Output | 1:2 |
| Series | 74HCT |
| Supplier Device Package | 16-PDIP |
| Type | Phase Lock Loop (PLL) |
| Voltage - Supply | 4.5V ~ 5.5V |
| 資料表 | 查看資料表PDF |
採購概覽
CD74HCT7046AE 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
CD74HCT7046AE 詳細描述
Product Overview
The CD74HCT7046AE from Harris Corporation is a phase lock loop (PLL) integrated circuit supplied in a through-hole 16-DIP (0.300 in, 7.62 mm) package, with the supplier device package listed as 16-PDIP. It is a single-circuit CMOS device with CMOS input and output interfaces, an input-to-output ratio of 1:2, and a maximum frequency rating of 38 MHz. The specified supply voltage range is 4.5 V to 5.5 V, and the operating temperature range is -55°C to 125°C.
