CY22388ZXC-30T

Product Overview

CY22388ZXC-30T is a Cypress Semiconductor (now part of Infineon Technologies) factory-programmable quad PLL clock generator with VCXO (Voltage Controlled Crystal Oscillator) functionality. The device integrates multiple phase-locked loops, programmable clock outputs and frequency selection features to generate multiple independent clock signals from a single crystal or reference clock source. With support for output frequencies up to 166MHz, 3.3V operation and a compact 16-pin TSSOP package, it is designed for digital systems requiring precise timing control, including networking equipment, consumer electronics, set-top boxes, storage devices and embedded control systems.

Key Features

• Manufacturer: Cypress Semiconductor / Infineon Technologies

• Part Number: CY22388ZXC-30T

• Product Type: Programmable Clock Generator

• Function: Factory-programmable Quad PLL Clock Generator with VCXO

• Integrated Circuit Type: Clock Generator / PLL Frequency Synthesizer

• Number of PLLs: 4 Integrated PLLs

• Number of Clock Outputs: Up to 8 Outputs

• Output Frequency Range: 1MHz to 166MHz

• Input Frequency Range: Crystal 10MHz to 30MHz / External Reference 1MHz to 100MHz

• Voltage Controlled Crystal Oscillator (VCXO): Integrated VCXO Function

• Supply Voltage: 3.3V

• Operating Supply Current: Approximately 60mA

• Clock Jitter: Approximately 250ps

• Frequency Selection: Programmable frequency select inputs

• Interface Type: Clock output and control interface

• Package Type: 16-TSSOP

• Mounting Type: Surface Mount Technology (SMT)

• Packaging: Tape and Reel

• Operating Temperature Range: Industrial temperature support depending on configuration

• MSL Rating: MSL 3 (168 hours)

• Compliance: Lead-free / RoHS compliant

• Typical Applications: Digital TV, DVD recorders, networking equipment, embedded systems, communication devices and consumer electronics

• Features: Multiple PLLs, programmable clock outputs, integrated VCXO and low-jitter timing generation

• Lifecycle Note: CY22388 series is an older Cypress clock generator family. Availability should be confirmed before new designs.

• Ordering Note: Buyers should verify programmed frequency configuration, package marking, date code and application requirements before production use.

Applications

CY22388ZXC-30T is suitable for electronic systems requiring multiple synchronized clock sources from a single reference oscillator. Typical applications include digital set-top boxes, DVD recorders, communication equipment, industrial controllers, embedded processors, storage systems and consumer multimedia devices. Its programmable PLL architecture helps reduce external oscillator components and simplifies system clock design.

Quality & Sourcing

Antrex Electronics can support CY22388ZXC-30T sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, marking verification, visual inspection and third-party testing support when required. OEMs, EMS providers, communication equipment manufacturers and electronic component buyers are welcome to send BOM lists or hard-to-find clock IC requirements for sourcing assistance.
