3382G-1-103G
Bourns 10kΩ 12mm SMD rotary position sensor with 330° rotation angle.
- 製造商
- Bourns Inc.
- 產品分類
- 專用 傳感器
- 封裝
- SMD
- 庫存
- 1,500 件
- 供貨狀態
- 當前數量需確認。
產品屬性
| 製造商 | Bourns Inc. |
|---|---|
| 產品分類 | 專用 傳感器 |
| Actuator Type | Shaft Hole |
| Applications | Test equipment, robotics, medical equipment, consumer electronics, small engines |
| Country of Origin | Taiwan |
| Linearity | ±2% |
| Mechanical Life | 1,000,000 rotational cycles |
| Moisture Sensitivity Level | MSL 1 |
| Mounting Type | Surface Mount (SMD/SMT) |
| Operating Temperature Range | -40°C to +120°C |
| Output Type | Analog Resistive Output |
| Package Type | 4-SMD Gull Wing |
| Packaging | Tape & Reel |
| Part Number | 3382G-1-103G |
| Product Type | Rotary Position Sensor |
| Qualification | AEC-Q100 / Automotive qualified version |
| Resistance Tolerance | ±30% |
| Resistance Value | 10 kΩ |
| RoHS Compliance | ROHS compliant |
| Rotation Angle | 330° continuous |
| Sensor technology | Resistive |
| Supply Voltage Maximum | 16V |
| Termination Style | SMD Tab |
| 資料表 | 索取數據表 |
採購概覽
3382G-1-103G 的主要供貨及採購資訊。
為何選擇 Antrex Electronics？
為已核實的採購、檢驗及國際採購需求提供獨立分銷支援。
獨立分銷支援
支援短缺、停產及難找電子元器件的生產與採購需求。
可追溯性審查
可在訂單確認前審查標籤、批號、生產批次及現有供應鏈文件。
檢驗與測試
如有需要，可安排外觀檢查、X-ray 及第三方測試支援。
全球採購支援
支援 OEM、EMS、分銷商的國際採購需求，涵蓋單一料號及 BOM 專案。
資質與驗證支援
為電子元器件採購提供品質控制、可追溯性審查及檢驗支援。
3382G-1-103G 詳細描述
Product Overview
3382G-1-103G is a Bourns 3382 Series 12mm rotary position sensor designed for accurate angle measurement and control applications. This surface-mount resistive position sensor features a 10kΩ resistance value, 330° electrical travel angle and analog output signal. With compact PCB mounting, low-profile construction and reliable position sensing performance, it is suitable for automotive electronics, industrial equipment, robotics, medical devices and control systems requiring rotary position feedback.
Key Features
Manufacturer: Bourns
Part Number: 3382G-1-103G
Product Series: 3382 Series
Product Type: Rotary Position Sensor
Sensor Technology: Resistive
Output Type: Analog
Resistance Value: 10kΩ
Resistance Tolerance: ±30%
Electrical Travel Angle: 330°
Linearity: ±2%
Mounting Type: Surface Mount Technology (SMD/SMT)
Package Size: 12mm square low-profile design
Shaft Style: Shaft hole design
Supply Voltage Maximum: 16V
Power Rating: 50mW
Temperature Coefficient: ±500ppm/°C
Operating Temperature Range: -40°C to +120°C
Number of Turns: Single turn
Number of Gangs: 1
Contact Resistance Variation: Low variation design for stable output
Mounting Method: PCB surface mounting
Compliance: RoHS compliant
Qualification: AEC-Q200 compliant
Features: Compact rotary sensing, analog position output, high reliability and automotive-grade durability
Typical Applications: Robotics, automotive controls, medical equipment, test instruments, industrial automation and user interface controls
Ordering Note: Buyers should verify resistance value, mounting dimensions, travel angle and packaging requirements before production use.
Applications
3382G-1-103G is designed for applications requiring precise rotary position feedback in compact electronic systems. Typical applications include throttle position sensing, control panels, industrial instrumentation, robotics, medical equipment, consumer electronics, test and measurement devices and automotive control systems.
Quality & Sourcing
Antrex Electronics can support 3382G-1-103G sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.
For quality control, Antrex Electronics can help arrange product photos, label review, visual inspection and third-party testing support when required. OEMs, EMS providers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find part requests for sourcing assistance.
