PS22A79
1200V 50A Mitsubishi DIPIPM with integrated IGBT drivers for 3-phase motor inverters
- ПРОИЗВОДИТЕЛЬ
- Mitsubishi Electric
- КАТЕГОРИЯ ТОВАРА
- Силовые драйверные модули
- Корпус
- MODULE
- Склад
- 500 шт.
- Наличие
- Текущее количество требует подтверждения.
Характеристики товара
| ПРОИЗВОДИТЕЛЬ | Mitsubishi Electric |
|---|---|
| КАТЕГОРИЯ ТОВАРА | Силовые драйверные модули |
| Case Operating Temperature | -20°C to +100°C |
| Collector Current (IC) | 50 A |
| Collector Dissipation | 129.9 W per IGBT chip |
| Collector-Emitter Voltage (VCES) | 1200 V |
| Configuration | 3-phase DC/AC inverter |
| Control Supply Voltage | 15 V Typical |
| IGBT Technology | 6th Generation LPT-CSTBT |
| Input Interface | 3 V / 5 V Schmitt Trigger, High Active |
| Isolation Voltage | 2500 Vrms |
| Junction Temperature | -20°C to +150°C |
| Maximum Control Supply Voltage | 20 V |
| Package Type | Insulated Transfer Molded Large DIPIPM |
| Peak Collector Current (ICP) | 100 A |
| Product Type | Intelligent Power Module (DIPIPM) |
| Short-Circuit Trip Level | 85 A Minimum |
| Storage Temperature | -40°C to +125°C |
| Supply Voltage (VCC) | 900 V |
| Surge Supply Voltage | 1000 V |
| Техническая документация | Запросить даташит |
Сводка по закупке
Основная информация о поставке и закупке для PS22A79.
Почему выбирают Antrex Electronics?
Независимая дистрибьюторская поддержка для проверенных закупок, инспекции и международных требований к поставкам.
Поддержка независимого дистрибьютора
Поиск дефицитных, снятых с производства и труднодоступных компонентов для производственных и закупочных задач.
Проверка прослеживаемости
До подтверждения заказа можно проверить этикетку, партию, дату производства и доступную документацию по цепочке поставок.
Инспекция и тестирование
При необходимости можно организовать визуальную проверку, рентген и тестирование третьей стороной.
Глобальная поддержка закупок
Поддержка международных закупок для OEM, EMS и дистрибьюторов — от отдельных компонентов до BOM-проектов.
Сертификация и поддержка проверки
Контроль качества, проверка прослеживаемости и инспекционная поддержка для закупок электронных компонентов.
Подробное описание PS22A79
Product Overview
PS22A79 is a Mitsubishi Electric intelligent power module (IPM) designed for compact inverter and motor control applications. This module integrates high-voltage IGBT power devices, free-wheeling diodes and gate drive/protection circuits into a single package, providing efficient switching performance, simplified system design and enhanced reliability. With integrated protection functions and optimized power characteristics, PS22A79 is suitable for industrial automation, motor drives, HVAC systems and general-purpose inverter applications.
Key Features
Manufacturer: Mitsubishi Electric
Part Number: PS22A79
Product Type: Intelligent Power Module (IPM)
Semiconductor Technology: IGBT power module
Module Function: Integrated inverter power switching solution
Configuration: Three-phase inverter bridge module
Integrated Components: IGBT chips, free-wheeling diodes and driver circuits
Protection Functions: Short-circuit, overcurrent and undervoltage protection
Gate Drive: Built-in drive and protection circuitry
Switching Performance: High-efficiency switching operation
Power Handling: Designed for compact motor control systems
Isolation Performance: Electrical isolation between power terminals and baseplate
Package Type: Compact IPM power package
Mounting Type: Screw mounting with heat sink installation
Thermal Performance: Optimized heat dissipation design
Operating Temperature: Industrial temperature range support
Application Category: Motor control and power conversion
Reliability Features: Integrated protection and rugged construction
Compliance: RoHS compliant
Ordering Note: Buyers should verify voltage rating, current rating, package dimensions and latest Mitsubishi Electric datasheet before production use.
Applications
PS22A79 is designed for compact power conversion systems requiring reliable inverter switching performance. Typical applications include AC motor drives, servo systems, industrial automation equipment, HVAC controllers, pumps, fans, consumer appliances and general-purpose inverter systems.
Quality & Sourcing
Antrex Electronics provides sourcing support for PS22A79 including stock verification, quotation service, package confirmation, date code review and shipment coordination. Customers can provide quantity requirements, delivery schedules and application details for efficient purchasing support.
For quality assurance, Antrex Electronics can assist with product marking verification, visual inspection and third-party testing services when required. Industrial equipment manufacturers, automation suppliers and electronic component buyers are welcome to submit BOM lists or hard-to-find power module requirements for sourcing assistance.
