VS-183NQ100PBF

Product Overview

VS-183NQ100PBF is a Vishay Semiconductors high-performance Schottky rectifier designed for high-current power conversion applications. Featuring a 100V reverse voltage rating and 180A average forward current capability, this single diode module provides low forward voltage drop, high-frequency operation and excellent thermal reliability. With Vishay proprietary barrier technology, guard ring protection and a HALF-PAK (D-67) package, VS-183NQ100PBF is suitable for switching power supplies, UPS systems, converters, welding equipment and reverse battery protection applications.

Key Features

• Manufacturer: Vishay Semiconductors

• Part Number: VS-183NQ100PBF

• Product Type: Schottky Rectifier Diode Module

• Rectifier Configuration: Single diode

• Technology: Schottky Barrier Rectifier

• Repetitive Peak Reverse Voltage (VRRM): 100V

• Maximum DC Reverse Voltage (VR): 100V

• Average Forward Current (IF(AV)): 180A

• Maximum Forward Current Capability: 240A under specified thermal conditions

• Surge Forward Current (IFSM): 22000A

• Forward Voltage Drop (VF): 0.73V typical at 180A and TJ=125°C

• Reverse Leakage Current: 4.5mA maximum

• Junction Temperature Range: -55°C to +175°C

• Maximum Junction Temperature: 175°C

• Package Type: HALF-PAK (D-67)

• Mounting Type: Chassis Mount

• Terminal Configuration: Lug terminal anode, base cathode

• Thermal Design: High-current module package for efficient heat dissipation

• Protection Features: Guard ring for enhanced ruggedness and reliability

• High Frequency Performance: Optimized for high-frequency switching operation

• Compliance: RoHS compliant

• Features: Low forward voltage drop, high current capability, high temperature operation and excellent reliability

• Typical Applications: Switching power supplies, UPS systems, converters, freewheeling diodes, welding equipment and reverse battery protection circuits

• Datasheet: VS-183NQ100PBF datasheet PDF available for technical verification before production use.
