SMW70N06-14
SMW70N06-14 is a 60V 70A N-channel enhancement-mode power MOSFET designed for high-current switching applications.
Quick Answer: SMW70N06-14 is a Vishay Siliconix / TEMIC N-channel enhancement-mode power MOSFET designed for high-current switching applications.
- Manufacturer
- Vishay General Semiconductor - Diodes Division
- Product Category
- MOSFET
- Package
- TO-3P
- Stock
- 1,500 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Vishay General Semiconductor - Diodes Division |
|---|---|
| Product Category | MOSFET |
| Applications | Motor Control, DC-DC Converters, Power Supplies, Battery Management, Industrial Switching Systems |
| Continuous Drain Current (Id) | 70A |
| Drain-Source On-Resistance (RDS(on)) | 0.014Ω Max @ VGS=10V |
| Drain-source voltage (Vdss) | 60V |
| Forward Transconductance (gfs) | 30S Typ. |
| Gate Threshold Voltage (VGS(th)) | 2V to 4V |
| Gate-Source Voltage (VGS) | ±20V |
| Input Capacitance (Ciss) | 3450pF Typ. |
| MOSFET Type | N-Channel Enhancement Mode |
| Mounting Type | Through Hole |
| Number of Pins | 3 Pins |
| Operating Junction Temperature | -55°C to +150°C |
| Output Capacitance (Coss) | 1000pF Typ. |
| Package Type | TO-247AD |
| Power Dissipation (Pd) | 150W |
| Pulsed Drain Current (IDM) | 280A |
| Reverse Transfer Capacitance (Crss) | 230pF Typ. |
| Technology | Silicon MOSFET |
| Total Gate Charge (Qg) | 95nC Typ. |
| Datasheet | Request Datasheet |
Procurement Snapshot
Key supply and purchasing information for SMW70N06-14.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for SMW70N06-14
Product Overview
SMW70N06-14 is a Vishay Siliconix / TEMIC N-channel enhancement-mode power MOSFET designed for high-current switching applications. The device features a 60V drain-source voltage rating, 70A continuous drain current capability and low on-state resistance of approximately 14mΩ. With a TO-247AD package, high power dissipation capability and fast switching performance, SMW70N06-14 is suitable for motor control, power converters, switching power supplies, battery systems and industrial power applications.
Key Features
Manufacturer: Vishay Siliconix / TEMIC Semiconductors
Part Number: SMW70N06-14
Device Type: N-Channel Enhancement Mode MOSFET
Product Category: Power Semiconductor / MOSFET
Drain-Source Voltage (VDS): 60V
Continuous Drain Current (ID): 70A
Pulsed Drain Current (IDM): 280A
Drain-Source On Resistance (RDS(on)): 0.014Ω maximum
Gate-Source Voltage (VGS): ±20V
Power Dissipation: 150W
Avalanche Current Capability: 70A
Repetitive Avalanche Energy: 245mJ
Channel Type: N-Channel
Switching Mode: High-speed power switching
Technology: Silicon MOSFET technology
Package Type: TO-247AD
Mounting Type: Through-hole mounting
Operating Temperature: -55°C to +150°C
Thermal Resistance Junction-to-Case: Approximately 0.83°C/W
Switching Application: Power conversion and load control
Typical Use: Motor drives, DC-DC converters, inverters, UPS systems and industrial power equipment
Ordering / Packaging Note: SMW70N06-14 buyers should verify manufacturer marking, package type, date code, lot traceability and electrical parameters before production use.
