MIG50Q7CSB1X

Product Overview

MIG50Q7CSB1X is a Toshiba intelligent power module (IPM) integrating silicon N-channel IGBTs, inverter circuits, brake circuits and built-in protection functions. The device is designed for high-power switching and motor control applications, featuring a 1200V voltage rating, 50A current capability and 7-in-1 integrated power stage configuration. With integrated IGBT drive circuits, short-circuit protection, over-current protection, under-voltage protection and over-temperature protection, it provides a compact and reliable solution for industrial motor drives, inverter systems and power conversion equipment.

Key Features

• Manufacturer: Toshiba Semiconductor

• Part Number: MIG50Q7CSB1X

• Full / Related Part Number: MIG50Q7CSB1X

• Device Type: Intelligent Power Module (IPM)

• Product Category: IGBT power module / motor control module

• Technology: Silicon N-channel IGBT with integrated control circuits

• Configuration: 7-in-1 integrated power module

• Voltage Rating: 1200V class

• Collector Current: 50A class

• Integrated Functions: Converter, inverter and brake power circuits

• Motor Drive Support: Three-phase inverter output for motor control applications

• Built-in Driver: Integrated IGBT gate drive circuits

• Protection Features: Short-circuit protection, over-current protection, under-voltage protection and over-temperature protection

• Collector-Emitter Saturation Voltage: 2.2V typical

• Electrical Isolation: Electrodes isolated from case structure

• Package Type: Intelligent power module package

• Weight: Approximately 278g

• Compliance: UL recognized component (File No. E87989)

• Typical Use: Industrial motor drives, inverter systems and high-power switching equipment

• Ordering / Packaging Note: MIG50Q7CSB1X buyers should verify manufacturer, package marking, voltage/current rating, date code and datasheet revision before production use.

Applications

MIG50Q7CSB1X is suitable for high-power switching applications including industrial motor control systems, variable frequency drives (VFD), servo drives, industrial automation equipment, inverter systems, renewable energy converters, UPS equipment and other power electronics applications. Its integrated inverter, brake circuit and protection functions help simplify system design and improve reliability in demanding industrial environments.

Quality & Sourcing

Antrex Electronics can support MIG50Q7CSB1X sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, label review, visual inspection and third-party testing support when required. OEMs, EMS providers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find part requests for sourcing assistance.
