TPS78001DRVT
IC REG LIN POS ADJ 150MA 6WSON
Quick Answer: The TPS78001DRVT from Texas Instruments is a single-output linear voltage regulator for positive adjustable regulation.
- Manufacturer
- Texas Instruments
- Product Category
- Voltage Regulators & Voltage Controllers
- Package
- 6-WDFN Exposed Pad
- Stock
- 29,242 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Texas Instruments |
|---|---|
| Product Category | Voltage Regulators & Voltage Controllers |
| Control Features | Enable |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 800 nA |
| Current - Supply (Max) | 5 µA |
| Min Qty | 1 |
| Mounting Type | Surface Mount |
| Number of Regulators | 1 |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Package | Tape & Reel (TR),Cut Tape (CT) |
| Product status | Active |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| PSRR | 40dB ~ 15dB (10Hz ~ 1kHz) |
| Supplier Device Package | 6-WSON (2x2) |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Max) | 5.25V |
| Voltage - Output (Min/Fixed) | 1.22V |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for TPS78001DRVT.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for TPS78001DRVT
Product Overview
The TPS78001DRVT from Texas Instruments is a single-output linear voltage regulator for positive adjustable regulation. It accepts input voltages up to 5.5 V and provides an adjustable output range of 1.22 V to 5.25 V at up to 150 mA. The device provides a compact surface-mount power rail with 800 nA quiescent current and enable control. It is packaged in a 6-WDFN exposed-pad case, 6-WSON (2x2), and operates from -40°C to 125°C.
Key Features
- Provides one positive adjustable output with a maximum output current of 150 mA.
- Accepts input voltages up to 5.5 V and supports output settings from 1.22 V to 5.25 V.
- Draws 800 nA quiescent current and has a maximum supply current of 5 µA.
- Includes an enable control feature for output activation or deactivation.
- Includes over-current, over-temperature, and reverse-polarity protection.
- Operates from -40°C to 125°C.
- Uses a 6-WDFN exposed-pad surface-mount package, 6-WSON (2x2).
Applications
- Battery-powered sensor and monitoring devices requiring a positive adjustable rail up to 150 mA.
- Portable instruments and handheld equipment using a single adjustable supply rail for analog or digital circuits.
- Embedded control boards using an enable-controlled regulator output.
- Compact surface-mount power delivery in designs constrained by the 6-WSON (2x2) package outline.
Design & Procurement Notes
Designers should verify that the selected output voltage remains within 1.22 V to 5.25 V and that the input voltage does not exceed 5.5 V. Because the regulator is adjustable, the output setting should be checked against the load requirement and the 150 mA output current limit. The enable control can be used to manage the output state. Over-current, over-temperature, and reverse-polarity protection should be considered as part of the overall power design. The 6-WDFN exposed-pad package requires a compatible surface-mount footprint and assembly process. For operation near the voltage or current limits, confirm board layout and thermal management under the intended -40°C to 125°C conditions.
TPS78001DRVT Sourcing & Availability Support
RFQ SupportTPS78001DRVT is listed under the Voltage Regulators & Voltage Controllers category from Texas instruments. It is commonly reviewed for power management, voltage regulation, DC-DC conversion, battery charging, power supply circuits, industrial electronics, communication equipment and embedded systems. Buyers can request current stock, price, lead time, date code, packaging photos and RFQ support from Antrex Electronics.
Product review notes
TPS78001DRVT belongs to the Voltage Regulators & Voltage Controllers category from Texas instruments. This page is designed for OEM, EMS, industrial and electronic component buyers who need sourcing support, availability checks and purchasing assistance. Antre...
RFQ checklist
- Current stock, price and lead time
- Date code, package type and label photos
- Reel, tray, tube or cut-tape condition
- Target price, volume demand and BOM requirements
FAQ for TPS78001DRVT
What is TPS78001DRVT?
TPS78001DRVT is listed under the Voltage Regulators & Voltage Controllers category from Texas instruments. Buyers can request stock, price, lead time and sourcing support from Antrex Electronics.
Who manufactures TPS78001DRVT?
The manufacturer of TPS78001DRVT is Texas instruments. Please confirm the full part number, package, date code and application requirements before placing an order.
Can I request stock and price for TPS78001DRVT?
Yes. You can send an RFQ to Antrex Electronics to check current stock, price, lead time, date code, packaging condition and volume quotation for TPS78001DRVT.
