CD4011BF

Product Overview

CD4011BF is a Texas Instruments CMOS quad 2-input NAND gate integrated circuit designed for general-purpose digital logic applications. The device contains four independent NAND gates with buffered outputs, wide operating voltage range from 3V to 18V and low power CMOS operation. With military-grade temperature capability and a 14-pin ceramic DIP package, it is suitable for industrial control systems, digital logic circuits, timing applications, interface circuits and high-reliability electronic equipment.

Key Features

• Manufacturer: Texas Instruments

• Part Number: CD4011BF

• Device Type: CMOS Logic NAND Gate IC

• Product Category: Logic IC / Gate IC

• Logic Function: Quad 2-Input NAND Gate

• Number of Gates: 4 Independent NAND Gates

• Number of Inputs: 2 Inputs Per Gate

• Technology: CMOS

• Supply Voltage Range: 3V to 18V

• Operating Voltage: 5V, 10V and 15V Typical CMOS Logic Levels

• Output Type: Buffered CMOS Output

• Input Compatibility: CMOS Logic Level Compatible

• Low Power Consumption: CMOS Low Static Power Operation

• Propagation Delay: Depends on Supply Voltage and Load Conditions

• Noise Immunity: High CMOS Noise Margin

• Package Type: Ceramic Dual In-Line Package (CDIP)

• Pin Count: 14 Pins

• Mounting Type: Through Hole

• Operating Temperature Range: -55°C to +125°C

• Qualification: Military Grade

• Applications: Digital Logic Control, Timing Circuits, Oscillators and Signal Processing

• Ordering / Packaging Note: Buyers should verify complete ordering code, package type, temperature grade, manufacturer marking and military qualification requirements before production use.
