GW45HF60WD
The GW45HF60WD is a 45A, 600V ultra-fast IGBT from STMicroelectronics, featuring an integrated soft recovery antiparallel diode and optimized for high-frequency switching applications above 100kHz, including welding equipment, power factor correction, and high-frequency converters.
Quick Answer: GW45HF60WD (STGW45HF60WD) is a high-speed N-channel IGBT from STMicroelectronics featuring an ultra-fast soft recovery antiparallel diode.
- Manufacturer
- STMicroelectronics
- Product Category
- IGBT Transistors
- Package
- TO-247
- Stock
- 1,500 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | STMicroelectronics |
|---|---|
| Product Category | IGBT Transistors |
| Applications | Welding Equipment, High-Frequency Converters, Power Factor Correction, Induction Heating Systems |
| Collector Current at TC=100°C | 30 A |
| Collector-Emitter Saturation Voltage (VCE(sat)) | 2.5 V max |
| Collector-Emitter Voltage (VCES) | 600 V |
| Continuous Collector Current (IC) | 45 A |
| Gate Threshold Voltage (VGE(th)) | 4.0 V to 6.0 V |
| Gate-Emitter Voltage (VGE) | ±20 V |
| Integrated Diode | Ultra-Fast Soft Recovery Diode |
| Mounting Type | Through Hole |
| Operating Junction Temperature | -55°C to +150°C |
| Package Type | TO-247 |
| Power Dissipation (Ptot) | 250 W |
| Product Type | Insulated Gate Bipolar Transistor (IGBT) |
| Pulsed Collector Current (ICM) | 150 A |
| Reverse Recovery Time (trr) | 55 ns typ. |
| RoHS Compliant | Yes |
| Switching Frequency | Above 100 kHz |
| Technology | Planar IGBT Technology |
| Total Gate Charge (Qg) | 160 nC typ. |
| Turn-off Delay Time | 145 ns typ. |
| Turn-on Delay Time | 30 ns typ. |
| Datasheet | Request Datasheet |
Procurement Snapshot
Key supply and purchasing information for GW45HF60WD.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for GW45HF60WD
Product Overview
GW45HF60WD (STGW45HF60WD) is a high-speed N-channel IGBT from STMicroelectronics featuring an ultra-fast soft recovery antiparallel diode. Designed with advanced planar IGBT technology, the device provides stable switching performance at elevated temperatures, low conduction losses and optimized turn-off characteristics. With a 600V voltage rating and high-frequency switching capability, it is suitable for welding equipment, high-frequency converters, power factor correction systems and industrial power applications. :contentReference[oaicite:0]{index=0}
Key Features
Manufacturer: STMicroelectronics
Part Number: GW45HF60WD / STGW45HF60WD
Device Type: N-Channel Insulated Gate Bipolar Transistor (IGBT)
Product Category: Discrete Power Semiconductor
Configuration: Single IGBT with Integrated Antiparallel Diode
Technology: Advanced Planar IGBT Technology
Collector-Emitter Voltage (VCES): 600V
Continuous Collector Current: 70A at TC=25°C
Continuous Collector Current: 45A at TC=100°C
Pulsed Collector Current (ICM): 150A
Gate-Emitter Voltage (VGES): ±20V
Collector-Emitter Saturation Voltage (VCE(sat)): Approximately 2.5V
Gate Charge (Qg): Approximately 160nC
Integrated Diode: Ultra Fast Soft Recovery Antiparallel Diode
Diode Reverse Recovery Time (trr): Approximately 55ns
Low CRES/CIES Ratio for Reduced Cross-Conduction Risk
Improved Turn-Off Energy Performance at High Temperature
Maximum Power Dissipation: 250W
Junction Temperature Range: -55°C to +150°C
Thermal Resistance Junction-Case: 0.5°C/W (IGBT)
Package Type: TO-247
Mounting Type: Through Hole
Pin Configuration: Gate, Collector, Emitter
High Frequency Switching Capability: Over 100kHz Class Applications
Application Type: High-Efficiency Power Switching
Typical Applications: Welding Equipment, High Frequency Converters, Power Factor Correction, Industrial Inverters and Switching Power Supplies
Product Status: Legacy / Industrial Maintenance Component
Ordering Note: Verify marking code, package type, date code and electrical parameters before production use.
Applications
GW45HF60WD is designed for high-frequency power conversion systems requiring fast switching speed, low switching loss and reliable thermal performance. Typical applications include welding machines, high-frequency converters, power factor correction circuits, industrial power supplies, motor control systems and inverter equipment. :contentReference[oaicite:1]{index=1}
Quality & Sourcing
Antrex Electronics can support GW45HF60WD sourcing with stock availability checks, RFQ quotation, manufacturer verification, package confirmation, date code review and shipment arrangement. For IGBT sourcing projects, buyers can provide quantity requirements, acceptable date codes, package requirements and application information for faster quotation support.
For quality control, Antrex Electronics can help arrange product photos, marking review, visual inspection, electrical testing and third-party verification when required. OEMs, EMS providers, industrial equipment manufacturers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find power semiconductor requests.
