GIPS20K60

Product Overview

GIPS20K60 is the marking code for the STMicroelectronics STGIPS20K60 intelligent power module (IPM). It is a SLLIMM™ (Small Low-Loss Intelligent Molded Module) integrating a 600V, 17A three-phase IGBT inverter bridge, gate driver ICs and free-wheeling diodes in a compact SDIP-25L package. The module is designed for low-power motor drives and home appliance inverters, providing high efficiency, short-circuit ruggedness and built-in protection functions.  :contentReference[oaicite:0]{index=0}

Key Features

• Manufacturer: STMicroelectronics

• Part Number: STGIPS20K60 (Marking: GIPS20K60)

• Device Type: Intelligent Power Module (IPM)

• Series: SLLIMM™ Small Low-Loss Intelligent Molded Module

• Configuration: 3-Phase IGBT Inverter Bridge

• Collector-Emitter Voltage (VCES): 600V

• Continuous Output Current: 17A to 18A

• IGBT Technology: Short-Circuit Rugged IGBTs

• Integrated Diodes: Free-Wheeling Diodes Included

• Input Logic Compatibility: 3.3V, 5V and 15V CMOS/TTL

• Built-in Bootstrap Diodes: Yes

• Undervoltage Lockout Protection: Yes

• Interlocking Function: Integrated

• Smart Shutdown Function: Supported

• Overcurrent Protection Comparator: Integrated

• Overtemperature Protection Comparator: Integrated

• Isolation Voltage: 2500Vrms/min

• Substrate Technology: DBC (Direct Bonded Copper)

• Maximum Junction Temperature: 125°C

• Operating Temperature Range: -40°C to +125°C

• Package Type: SDIP-25L / 25-PowerDIP Module

• Mounting Type: Through Hole

• Packaging: Tube

• Application Type: AC Motor Drive and Inverter Control

• Typical Applications: Washing Machines, Refrigerators, Air Conditioners and Low-Power Industrial Inverters

• Lifecycle Status: Obsolete

• Recommended Replacement: STGIB15CH60TS-L
