95M02RD

Product Overview

95M02RD is commonly associated with STMicroelectronics M95M02-DR series, a 2 Mbit serial SPI bus EEPROM memory device. The device is organized as 262,144 x 8 bits and is accessed through a standard SPI-compatible serial interface. With 1.8V to 5.5V class supply operation for the M95M02-DR version, 256-byte page structure, high endurance, long data retention and compact 8-pin package options, it is suitable for configuration storage, calibration data, identification memory, industrial control boards, metering equipment, communication systems, consumer electronics and embedded system applications.

Key Features

• Manufacturer: STMicroelectronics

• Marking / Short Part Number: 95M02RD

• Full / Related Part Number: M95M02-DR, M95M02-DRMN6TP, M95M02-DRCS6TP and related variants

• Device Type: Serial SPI EEPROM memory

• Product Category: Memory IC / non-volatile EEPROM

• Memory Size: 2 Mbit

• Memory Organization: 262,144 x 8 bits

• Interface Type: SPI-compatible serial bus

• Clock Frequency: 5MHz class depending on voltage and datasheet version

• Supply Voltage: 1.8V to 5.5V for M95M02-DR version depending on operating condition

• Page Size: 256 bytes

• Write Feature: Byte write and page write support

• Write Protection: Quarter, half or whole memory array protection depending on register setting

• Identification Page: Additional lockable identification page supported depending on datasheet version

• Endurance: More than 4 million write cycles depending on operating condition

• Data Retention: More than 200-year data retention depending on datasheet condition

• Package Options: SO8N and WLCSP8 package variants depending on full ordering code

• Mounting Type: Surface mount

• Key Features: 2 Mbit EEPROM density, SPI serial interface, 256-byte page size, wide supply voltage range, high endurance, long data retention and compact package options

• Typical Use: Configuration memory, calibration data storage, identification memory, industrial control boards, metering equipment, communication equipment and embedded systems

• Ordering / Packaging Note: 95M02RD is usually a shortened marking-style reference for M95M02-DR variants; buyers should verify the full ST ordering code, package suffix, voltage option, top marking, packing format, temperature grade and datasheet revision before production or repair use.

Applications

95M02RD can be used in electronic systems that require 2 Mbit non-volatile EEPROM memory for configuration, calibration, identification and data storage. Typical applications include industrial control boards, smart meters, communication equipment, consumer electronics, embedded controllers, medical devices, power management systems, sensor modules, security systems, maintenance projects and repair applications. It is also suitable for BOM review where an STMicroelectronics 2 Mbit SPI EEPROM memory device is required.

Quality & Sourcing

Antrex Electronics can support 95M02RD sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, label review, visual inspection and third-party testing support when required. OEMs, EMS providers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find part requests for sourcing assistance.
