SKM75GB12T4
SEMIKRON SKM75GB12T4 is a fast 1200V 75A IGBT4 half-bridge power module with CAL4 diode technology, designed for high-frequency industrial inverter and motor drive applications
Quick Answer: SKM75GB12T4 is a SEMIKRON SEMITRANS 2 Fast IGBT power module designed for high-frequency switching and industrial power conversion applications.
- Manufacturer
- SEMIKRON
- Product Category
- IGBT Modules
- Package
- MODULE
- Stock
- 150 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | SEMIKRON |
|---|---|
| Product Category | IGBT Modules |
| Applications | AC Inverters, UPS, Electronic Welders, Motor Drives |
| Baseplate Technology | Insulated Copper Baseplate with DBC |
| Collector Current (IC) | 75 A |
| Collector-Emitter Saturation Voltage (VCEsat) | 1.8 V typical |
| Configuration | Half Bridge Module |
| Diode Type | CAL4 Soft Recovery Freewheeling Diode |
| Gate-Emitter Voltage (VGES) | ±20 V |
| Integrated Gate Resistor | Yes |
| Isolation Voltage | 2500 V AC |
| Mounting Type | Screw Mount |
| Operating Temperature Range | -40°C to +150°C |
| Package Type | SEMITRANS 2 |
| Product Type | IGBT Power Module |
| Reverse Voltage (VRRM) | 1200 V |
| RoHS Status | Compliant |
| Switching Frequency | Up to 20 kHz |
| Technology | IGBT4 Fast Trench IGBT |
| Thermal Resistance (RthJC) | Low Thermal Resistance Design |
| Voltage Rating (VCES) | 1200 V |
| Weight | Approximately 160 g |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for SKM75GB12T4.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for SKM75GB12T4
Product Overview
SKM75GB12T4 is a SEMIKRON SEMITRANS 2 Fast IGBT power module designed for high-frequency switching and industrial power conversion applications. Featuring a 1200V collector-emitter voltage rating, 75A current capability, IGBT4 Fast Trench technology and integrated CAL4 soft-switching diode, this module provides low switching losses, high power cycling capability and excellent thermal performance. It is suitable for AC inverter drives, UPS systems, welding equipment and other high-efficiency power electronics applications.
Key Features
Manufacturer: SEMIKRON Danfoss
Part Number: SKM75GB12T4
Product Type: IGBT Power Module
Series: SEMITRANS 2
Technology: IGBT4 Fast Trench Technology
Configuration: Half-Bridge IGBT Module
Collector-Emitter Voltage (VCES): 1200V
Collector Current (IC): 75A
Continuous Collector Current: 115A
Collector-Emitter Saturation Voltage (VCE(sat)): 1.85V typical
Diode Technology: CAL4 soft switching freewheeling diode
Gate Drive: Integrated gate resistor
Package Type: SEMITRANS 2 module package
Dimensions: 94mm × 34mm × 30mm
Insulation Technology: Insulated copper baseplate with DBC technology
Mounting Type: Panel mounting
Switching Frequency Capability: Suitable for applications up to 20kHz
Junction Temperature Range: Up to +175°C
Features: Low switching losses, high power cycling capability and reliable thermal performance
Typical Applications: AC inverter drives, UPS systems, electronic welders and industrial converters
Datasheet: SKM75GB12T4 datasheet PDF available for technical verification before production use.
Applications
SKM75GB12T4 is designed for high-speed switching applications requiring efficient power conversion and reliable operation. Typical applications include variable frequency drives (VFD), industrial motor controllers, UPS equipment, welding machines, renewable energy converters, power supplies and other industrial power electronics systems.
