SKM100GAL12T4
SEMIKRON SKM100GAL12T4 is a 1200V 100A fast IGBT4 power module with CAL4 soft recovery diode, designed for high-frequency switching applications such as DC/DC converters and motor drives
Quick Answer: SKM100GAL12T4 is a SEMIKRON SEMITRANS 2 Fast IGBT power module designed for high-frequency switching and industrial power conversion applications.
- Manufacturer
- SEMIKRON
- Product Category
- IGBT Modules
- Package
- MODULE
- Stock
- 150 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | SEMIKRON |
|---|---|
| Product Category | IGBT Modules |
| Applications | DC/DC Converters, Brake Choppers, Motor Drives, Welding Equipment |
| Baseplate Technology | Insulated Copper Baseplate with DBC |
| Collector Current (IC) | 100 A |
| Collector-Emitter Saturation Voltage (VCE(sat)) | 1.8 V typical |
| Collector-Emitter Voltage (VCES) | 1200 V |
| Configuration | Single IGBT with Anti-Parallel Diode |
| Diode Type | CAL4 Soft Recovery Freewheeling Diode |
| Gate-Emitter Voltage (VGES) | ±20 V |
| Integrated Gate Resistor | Yes |
| Isolation Voltage | 4000 V AC |
| Maximum Collector Current (IC) | 160 A @ 25°C |
| Mounting Type | Screw Mount |
| Operating Junction Temperature | -40°C to +175°C |
| Package Type | SEMITRANS 2 |
| Peak Collector Current (ICRM) | 300 A |
| Product Type | IGBT Power Module |
| Reverse Voltage (VRRM) | 1200 V |
| RoHS Status | Compliant |
| Switching Frequency | Up to 20 kHz |
| Technology | IGBT4 Fast Trench Technology |
| Topology | Chopper / Booster |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for SKM100GAL12T4.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for SKM100GAL12T4
Product Overview
SKM100GAL12T4 is a SEMIKRON SEMITRANS 2 Fast IGBT power module designed for high-frequency switching and industrial power conversion applications. Featuring 1200V collector-emitter voltage capability, 100A current rating, IGBT4 Fast Trench technology and CAL4 soft-switching diode technology, this module delivers low switching losses, high short-circuit capability and excellent thermal performance. It is widely used in electronic welders, DC/DC converters, brake choppers and industrial motor control systems.
Key Features
Manufacturer: SEMIKRON Danfoss
Part Number: SKM100GAL12T4
Product Type: Fast IGBT Power Module
Series: SEMITRANS 2
Technology: IGBT4 Fast Trench Technology
Configuration: Single IGBT with inverse diode
Collector-Emitter Voltage (VCES): 1200V
Collector Current (IC): 100A
Continuous Collector Current: Up to 160A depending on operating conditions
Collector-Emitter Saturation Voltage (VCE(sat)): 1.8V typical
Diode Technology: CAL4 soft switching freewheeling diode
Short Circuit Capability: High short-circuit withstand capability with current self-limiting
Gate Drive: Integrated gate resistor
Package Type: SEMITRANS 2 module package
Dimensions: 94mm × 34mm × 30mm
Insulation Technology: Insulated copper baseplate with DBC technology
Switching Frequency: Suitable for applications up to 20kHz
Junction Temperature Range: -40°C to +175°C
Features: Low switching losses, high power cycling capability and high reliability
Typical Applications: Electronic welders, DC/DC converters, brake choppers and motor drives
Datasheet: SKM100GAL12T4 datasheet PDF available for technical verification before production use.
Applications
SKM100GAL12T4 is designed for high-speed and high-efficiency power switching systems. Typical applications include electronic welding equipment, DC/DC converters, brake chopper circuits, switched reluctance motor drives, industrial inverters and other high-performance power electronics platforms.
Quality & Sourcing
Antrex Electronics can support SKM100GAL12T4 sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, customers can provide quantity requirements, delivery schedules, application details and technical specifications for faster quotation support.
For quality assurance, Antrex Electronics can assist with product photos, marking verification, visual inspection and third-party testing services when required. OEM manufacturers, industrial equipment suppliers, repair centers and electronic component buyers are welcome to submit BOM lists or hard-to-find power semiconductor requirements for sourcing assistance.
