TSXDEZ32D2
Schneider Electric TSXDEZ32D2 is a Modicon TSX Micro 32-channel 24V DC digital input module for industrial automation systems
Quick Answer: TSXDEZ32D2 is a Schneider Electric Modicon TSX Micro discrete input module designed for industrial automation and PLC control systems.
- Manufacturer
- Schneider Electric
- Product Category
- PLC Modules
- Package
- DIN
- Stock
- 500 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Schneider Electric |
|---|---|
| Product Category | PLC Modules |
| Applications | Industrial Automation, Machine Control, Factory Equipment |
| Input Compatibility | 2/3-Wire Proximity Sensors PNP/NPN |
| Input Current | 7 mA |
| Input Impedance | 3.4 kΩ |
| Input Logic | Positive or Negative Logic |
| Input Type | Current Sink |
| Input Voltage | 24 VDC |
| Input Voltage Range | 19 VDC to 30 VDC |
| Isolation Voltage | 1500 VAC for 1 second |
| Mounting Type | PLC Rack Mount |
| Number of Inputs | 32 Inputs |
| Operating Temperature | Industrial Environment Compatible |
| Power Consumption | 254 mA |
| Product Series | Modicon TSX Micro |
| Product Type | Discrete Input Module |
| Response Time | 0.1 ms to 7.5 ms |
| Standards Compliance | IEC 1131-2 Type 2 |
| State 0 Current Threshold | ≤2 mA |
| State 1 Current Threshold | ≥6 mA |
| State 1 Voltage Threshold | ≥11 V |
| Terminal Type | Screw Terminal Block |
| Datasheet | Request Datasheet |
Procurement Snapshot
Key supply and purchasing information for TSXDEZ32D2.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for TSXDEZ32D2
Product Overview
TSXDEZ32D2 is a Schneider Electric Modicon TSX Micro discrete input module designed for industrial automation and PLC control systems. This module provides 32 digital DC inputs with compatibility for 2/3-wire PNP/NPN proximity sensors and supports 24V DC positive or negative logic input signals. Featuring reliable signal acquisition, IEC 1131-2 Type 2 compliance and high isolation performance, TSXDEZ32D2 is suitable for factory automation, machine control, process monitoring and industrial control applications.
Key Features
Manufacturer: Schneider Electric
Part Number: TSXDEZ32D2
Product Type: Discrete Input Module
Series: Modicon TSX Micro Automation Platform
Number of Inputs: 32 Digital Inputs
Input Type: DC Discrete Input
Input Voltage: 24V DC
Input Voltage Range: 19V to 30V DC
Input Current: 7mA typical
Input Logic: Positive or negative logic compatible
Input Compatibility: 2/3-wire proximity sensors PNP/NPN
Input Type: Current sink input
Input Impedance: 3.4Ω
State 1 Voltage Threshold: ≥11V
State 0 Voltage Threshold: <5V
Response Time: 0.1ms to 7.5ms
Isolation Voltage: 1500V AC for 1 second
Standards Compliance: IEC 1131-2 Type 2
Connection Type: Screw terminal block
Mounting Type: PLC module installation
Power Consumption: 254mA
Product Weight: Approx. 0.29kg
Features: Reliable digital signal input, sensor compatibility, industrial durability and easy PLC integration
Typical Applications: Industrial automation, machine control, factory equipment, process monitoring and PLC systems
Datasheet: TSXDEZ32D2 datasheet PDF available for technical verification before production use.
Applications
TSXDEZ32D2 is designed for industrial control systems requiring multiple digital input channels and reliable sensor signal processing. Typical applications include PLC-based automation systems, production lines, machine tools, material handling equipment, industrial monitoring systems and factory control solutions.
