1763-L16BWA
Allen-Bradley MicroLogix 1100 PLC with AC power, Ethernet, analog inputs and relay outputs
Quick Answer: 1763-L16BWA is an Allen-Bradley MicroLogix 1100 programmable logic controller (PLC) designed for compact industrial automation and machine control applications.
- Manufacturer
- Rockwell Automation
- Product Category
- Programmable (PLC, PAC)
- Package
- DIN
- Stock
- 1,500 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Rockwell Automation |
|---|---|
| Product Category | Programmable (PLC, PAC) |
| Analog Inputs | 2 × 0-10V DC voltage inputs |
| Catalog Number | 1763-L16BWA |
| Communication Ports | Ethernet and isolated RS-232/RS-485 |
| Communication Protocols | DF1, DH-485, Modbus RTU, ASCII, EtherNet/IP messaging |
| Controller Type | Programmable Logic Controller (PLC) |
| Data Memory | 4 KB user data memory |
| Digital Inputs | 10 × 24V DC inputs |
| Display | Embedded LCD display |
| Expansion Capability | Supports 1762 MicroLogix expansion I/O modules |
| Input Type | 24V DC sinking/sourcing type |
| Maximum Expansion | Up to 144 I/O points |
| Mounting Type | DIN rail or panel mounting |
| Operating Temperature | -20°C to 65°C |
| Output Type | Relay contact output |
| Power Supply | 120/240V AC |
| Program Memory | 4 KB user program memory |
| Relay Outputs | 6 relay outputs |
| Total I/O Points | 16 points |
| Total memory | 8 KB embedded memory |
| Datasheet | View Datasheet PDF |
Procurement Snapshot
Key supply and purchasing information for 1763-L16BWA.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for 1763-L16BWA
Product Overview
1763-L16BWA is an Allen-Bradley MicroLogix 1100 programmable logic controller (PLC) designed for compact industrial automation and machine control applications. This controller features 120/240V AC power input, 10 digital DC inputs, 2 analog voltage inputs, 6 relay outputs and built-in Ethernet communication capability. With 8 KB user memory, support for DF1, DH-485, Modbus RTU and EtherNet/IP messaging, 1763-L16BWA provides flexible control, communication and monitoring solutions for small-scale automation systems.
Key Features
Manufacturer: Allen-Bradley (Rockwell Automation)
Part Number: 1763-L16BWA
Product Type: Programmable Logic Controller (PLC)
Series: MicroLogix 1100
Controller Type: MicroLogix 1100 16 Point Controller
Power Supply: 120/240V AC
Digital Inputs: 10 × 24V DC Inputs
Analog Inputs: 2 × 10V Analog Voltage Inputs
Relay Outputs: 6 Relay Outputs
Memory Capacity: 8 KB User Memory
Communication Interfaces: Ethernet, Serial Communication
Communication Protocols: DF1, DH-485, Modbus RTU, ASCII, EtherNet/IP Messaging
Ethernet Port: Integrated Ethernet Interface
Input Signal Type: 24V DC
Output Signal Type: Relay
Programming Software: RSLogix 500
Mounting Type: DIN Rail Mount
Installation Orientation: Horizontal or Vertical Mounting
Operating Temperature Range: -20°C to +55°C
Storage Temperature Range: -40°C to +85°C
Dimensions: Approx. 90mm × 87mm × 110mm
Protection Features: Industrial-grade design for reliable operation
Application Type: Small automation and machine control systems
Features: Compact design, Ethernet connectivity, analog processing and flexible I/O expansion capability
Typical Applications: Packaging machines, conveyor systems, process control, OEM equipment and factory automation
Lifecycle Status: Discontinued product, available through specialized sourcing channels
Datasheet PDF: 1763-L16BWA technical documentation available from Rockwell Automation.
Applications
1763-L16BWA is suitable for compact automation systems requiring reliable PLC control, communication and data monitoring. Typical applications include industrial machinery, material handling systems, OEM equipment, building automation, production lines and small process control systems.
Quality & Sourcing
Antrex Electronics can support 1763-L16BWA sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, customers can provide quantity requirements, delivery schedules, application details and technical specifications for faster quotation support.
For quality assurance, Antrex Electronics can assist with product photos, marking verification, visual inspection and third-party testing services when required. OEM manufacturers, industrial automation suppliers and electronic component buyers are welcome to submit BOM lists or hard-to-find PLC requirements for sourcing assistance.
