SLG47104V

Product Overview

SLG47104V is a Renesas GreenPAK programmable mixed-signal IC. Although it appears in the website CPLD category, it is not a conventional macrocell CPLD: its value is the integration of configurable digital logic with device-specific analog and timing resources in a small mixed-signal matrix. It can replace combinations of glue logic, comparators, timers and simple supervisory circuits when the design is compiled for this exact GreenPAK target.

The ordering record identifies the device-specific GreenPAK operating range. The suffix maps to V GreenPAK ordering suffix. These details determine PCB compatibility, available I/O, timing limits, programming support and environmental suitability; a shared family name alone does not establish drop-in equivalence.

Architecture and Technical Characteristics

GreenPAK devices route configurable digital and analog building blocks through a mixed-signal connection matrix. Depending on the exact SLG member, those blocks can include lookup-table logic, D-type flip-flops, counters/delays, oscillators, analog comparators, voltage references, power-control or serial-interface functions. Resource counts vary significantly across the family. GreenPAK Designer must target the exact part, and a project compiled for a neighboring SLG number is not assumed pin-, resource- or image-compatible.

Key Features

• Manufacturer / historical brand: Renesas Electronics
• Full part number: SLG47104V
• Device classification: Renesas GreenPAK programmable mixed-signal IC
• Configuration technology: nonvolatile configurable mixed-signal matrix
• Voltage class: device-specific GreenPAK operating range
• Ordering suffix: V; confirm whether it denotes production IC, evaluation board or programming adapter
• Design flow: target the exact SLG device in Renesas GreenPAK Designer
• Mixed-signal resources: verify block type, count, routing and pin assignment in the exact device documentation

Applications

• Mixed-signal glue logic and board-level function integration
• Power sequencing, reset generation and supervisory timing
• Comparator-based threshold detection and signal qualification where supported
• Counters, delays, oscillators and compact state-control functions
• Space-constrained consumer, industrial, portable and embedded designs

Design and Replacement Considerations

Before replacing this GreenPAK device, compare the exact SLG base number, package, operating voltage, bonded pins, analog block complement, digital resources, oscillator behavior, nonvolatile memory configuration and GreenPAK Designer support. Determine whether the suffix identifies a production IC, evaluation board or programming adapter. Preserve the original project and programmed configuration: an unconfigured production device will not reproduce the customer circuit, and a configuration for another SLG member should not be loaded without recompilation and bench validation. Review thresholds, timing tolerances, start-up states and analog performance on the assembled board.

Quality & Sourcing

For SLG47104V, Antrex Electronics can support stock and lead-time checks, full-suffix confirmation, package and date-code review, photographs, label inspection and shipment planning. Buyers should state the required quantity, acceptable date code, packaging form, target application and whether blank or pre-programmed parts are needed. For discontinued or long-stored programmable devices, appropriate controls can include traceability review, marking comparison, lead or ball-condition inspection, solderability evaluation and third-party electrical or X-ray testing when project risk warrants it. OEMs, EMS providers, repair centers and component buyers may submit BOM lists or hard-to-find programmable-logic requirements for sourcing support.
