BCP56-16T

Product Overview

BCP56-16T is commonly associated with BCP56-16, an NPN medium power bipolar transistor designed for switching, amplification and driver applications. The device features an 80V collector-emitter voltage rating, 1A collector current capability and SOT-223 surface-mount package for improved thermal performance compared with smaller signal transistor packages. With medium-power handling, selected DC current gain group and low saturation voltage characteristics, it is suitable for linear regulators, MOSFET drivers, low-side switches, power management circuits, AF driver stages and industrial control boards.

Key Features

• Manufacturer: Multiple manufacturers including STMicroelectronics, onsemi, Nexperia and Infineon

• Part Number: BCP56-16T

• Base Part Number: BCP56-16

• Related Ordering Code: BCP56-16T1G commonly appears in onsemi tape-and-reel listings

• Device Type: NPN bipolar junction transistor

• Product Category: Discrete semiconductor / bipolar transistor / medium power transistor

• Polarity: NPN

• Transistor Technology: Silicon epitaxial planar transistor

• Collector-Emitter Voltage VCEO: 80V

• Collector-Base Voltage VCBO: 100V commonly listed

• Emitter-Base Voltage VEBO: 5V commonly listed

• Collector Current IC: 1A

• Peak Collector Current: Higher pulse current capability may be supported depending on manufacturer datasheet and thermal limits

• DC Current Gain Group: -16 gain selection group

• DC Current Gain hFE: 100 to 250 range commonly associated with the -16 gain group, subject to test condition and manufacturer

• Power Dissipation: 1.5W to 1.6W class commonly listed for SOT-223 package, depending on manufacturer and PCB conditions

• Saturation Feature: Low collector-emitter saturation voltage for switching and driver circuits

• Package: SOT-223

• Pin Count: 4 leads / tabs in SOT-223 package

• Mounting Type: Surface mount / SMT

• Packaging Note: T suffix may indicate tape packaging depending on manufacturer; confirm exact supplier ordering code before purchase

• Operating Junction Temperature: Up to +150°C commonly listed for many BCP56-16 versions

• Typical Use: Linear voltage regulators, MOSFET drivers, low-side switches, amplifiers and power management circuits

• Key Features: 80V rating, 1A collector current, NPN polarity, -16 gain group, SOT-223 package and medium-power surface-mount design

• Datasheet PDF: https://www.st.com/resource/en/datasheet/bcp56-16.pdf

• onsemi Datasheet Reference: https://www.onsemi.com/pdf/datasheet/bcp56t1-d.pdf

• Nexperia Product Reference: https://www.nexperia.com/product/BCP56-16

• DigiKey Product Reference: https://www.digikey.com/en/products/detail/stmicroelectronics/BCP56-16/1880153

• Ordering / Packaging Note: Buyers should verify the full manufacturer ordering code, T suffix meaning, SOT-223 package, gain group, top marking, date code, RoHS status, reel packaging and electrical requirements before production or repair use.
