CM300DC-24NFM

Product Overview

CM300DC-24NFM is a Mitsubishi Electric high-power IGBT module designed for industrial switching and power conversion applications. The device provides a 1200V collector-emitter voltage rating and 300A class current capability, featuring a dual IGBT configuration with integrated free-wheeling diodes. With high-speed switching performance, low conduction loss and a rugged industrial module structure, it is suitable for motor drives, inverter systems, UPS equipment, welding machines and high-power industrial power conversion applications.

Key Features

• Manufacturer: Mitsubishi Electric

• Part Number: CM300DC-24NFM

• Device Type: IGBT Power Module

• Product Category: Power Semiconductor Module

• Technology: Silicon IGBT + Free-Wheeling Diode

• Configuration: Dual IGBT Module / Half Bridge Configuration

• Collector-Emitter Voltage (VCES): 1200V

• Collector Current (IC): 300A

• Pulse Collector Current (ICM): High Pulse Current Capability

• Gate-Emitter Voltage (VGES): ±20V

• Maximum Power Dissipation: High Power Switching Capability

• Switching Performance: High-Speed Switching Operation

• Collector-Emitter Saturation Voltage: Low Conduction Loss Design

• Internal Structure: IGBT Chips with Anti-Parallel Diodes

• Isolation Voltage: High Electrical Isolation Between Terminals and Baseplate

• Package Type: Industrial Power Module Package

• Mounting Type: Screw Mount / Panel Mount

• Cooling Method: Heat Sink Cooling Required

• Operating Junction Temperature: Up to +150°C

• Application Type: High-Power Switching and Inverter Systems

• Typical Applications: Motor Drives, UPS Systems, Industrial Inverters and Power Conversion Equipment

• Product Status: Legacy / Verify Availability Before Production Use

• Ordering / Packaging Note: Buyers should verify Mitsubishi ordering code, module marking, terminal layout, gate drive requirements, cooling conditions and mechanical dimensions before production use.

Applications

CM300DC-24NFM is designed for high-power electronic systems requiring reliable switching performance and high current handling capability. Typical applications include industrial AC motor drives, variable frequency drives (VFD), servo amplifiers, inverter power supplies, renewable energy converters, UPS systems, welding equipment, industrial automation systems, power control cabinets and maintenance replacement projects requiring Mitsubishi 1200V / 300A IGBT modules.

Quality & Sourcing

Antrex Electronics can support CM300DC-24NFM sourcing with stock availability checks, RFQ quotation, manufacturer verification, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, label review, marking inspection, terminal inspection and third-party testing support when required. OEMs, EMS providers, industrial equipment manufacturers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find power module requests for sourcing assistance.

Datasheet

       Download CM300DC-24NFM Datasheet PDF
