CM150DY-24T

Product Overview

CM150DY-24T is a Mitsubishi Electric T-Series high-power insulated gate bipolar transistor (IGBT) module designed for high-current switching applications. This dual IGBT module integrates two IGBT elements and free-wheeling diodes in a half-bridge configuration, providing a 1200V collector-emitter voltage rating and 150A continuous collector current capability. Featuring Mitsubishi Electric’s advanced CSTBT™ technology, low power loss characteristics and high reliability, it is suitable for industrial motor drives, inverter systems, renewable energy equipment, UPS systems and high-power switching applications.

Key Features

• Manufacturer: Mitsubishi Electric

• Part Number: CM150DY-24T

• Product Type: IGBT Power Module

• Series: T Series IGBT Module

• Configuration: Dual IGBT (Half-Bridge)

• Technology: Silicon IGBT with free-wheeling diode

• Collector-Emitter Voltage (VCES): 1200V

• Collector Current (IC): 150A

• Isolation Voltage: 4000Vrms

• Collector-Emitter Saturation Voltage: Approximately 1.65V

• Maximum Junction Temperature: 175°C

• Operating Temperature Range: -40°C to +150°C

• Gate Drive Type: Voltage-controlled insulated gate drive

• Switching Application: High-power switching and inverter operation

• Package Type: Standard insulated power module package

• Mounting Type: Through-hole power module mounting

• Terminal Type: Nickel-plated tab terminals

• Technology Advantage: Low conduction loss and improved thermal reliability

• Reliability Feature: Enhanced thermal cycle lifetime design

• Compliance: RoHS compliant

• Typical Applications: AC motor control, servo drives, industrial inverters, UPS systems, power supplies and renewable energy equipment

• Features: High voltage capability, high current handling, low switching loss and robust industrial performance

• Lifecycle Note: CM150DY-24T is an active Mitsubishi Electric power module product. Availability should be confirmed for production requirements.

• Ordering Note: Buyers should verify module condition, date code, package marking, electrical parameters and application requirements before installation.

Applications

CM150DY-24T is designed for high-power electronic systems requiring efficient switching and reliable power conversion. Typical applications include industrial motor drives, motion control systems, servo amplifiers, solar inverters, wind power converters, UPS equipment, industrial power supplies and other high-voltage switching platforms. Mitsubishi Electric T-Series IGBT modules are widely used in industrial equipment requiring high reliability and reduced power losses.

Quality & Sourcing

Antrex Electronics can support CM150DY-24T sourcing with stock availability checks, RFQ quotation, package confirmation, date code review and shipment arrangement. For project-based purchasing, buyers can provide quantity, target price, required date code, packaging requirements and application information for faster quotation support.

For quality control, Antrex Electronics can help arrange product photos, marking verification, visual inspection and third-party testing support when required. OEMs, industrial automation companies, power electronics manufacturers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find IGBT module requirements for sourcing assistance.
