JTX1N5806
The JTX1N5806 is a military-grade fast recovery rectifier diode from Microchip Technology (formerly Microsemi), designed for high-reliability switching power applications, offering low forward voltage drop and fast reverse recovery performance
Quick Answer: JTX1N5806 is a military-grade fast recovery rectifier diode manufactured by Microchip Technology (formerly Microsemi).
- Manufacturer
- Microchip Technology
- Product Category
- Rectifiers
- Package
- DO-41
- Stock
- 1,500 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Microchip Technology |
|---|---|
| Product Category | Rectifiers |
| Applications | Switching Power Supplies, Military Electronics, Aerospace Systems, High-Speed Rectification, Pulse Circuits |
| Average Rectified Forward Current (IO) | 1 A |
| Configuration | Single Diode |
| Diode Type | Silicon Rectifier Diode |
| Forward Voltage Drop (VF) | 0.875 V max @ IF = 1 A |
| Junction Capacitance | 25 pF typ. |
| Maximum Reverse Voltage (VRRM) | 150 V |
| Mounting Type | Through Hole |
| Operating Junction Temperature | -65°C to +175°C |
| Package Type | Axial Leaded Package (Case A) |
| Peak Forward Surge Current (IFSM) | High Surge Capability |
| Product Type | Fast Recovery Rectifier Diode |
| Qualification Standard | MIL-PRF-19500/477 |
| Radiation Performance | Radiation Hardened Options Available |
| Recovery Type | Ultrafast / Fast Recovery |
| Reliability Grade | Military Grade (JANTX) |
| Reverse Leakage Current (IR) | 1 µA max @ VR = 150 V |
| Reverse Recovery Time (trr) | 25 ns typ. |
| RoHS Status | Military leaded versions available |
| Technology | Fast Recovery PN Junction |
| Datasheet | Request Datasheet |
Procurement Snapshot
Key supply and purchasing information for JTX1N5806.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for JTX1N5806
Product Overview
JTX1N5806 is a military-grade fast recovery rectifier diode manufactured by Microchip Technology (formerly Microsemi). The device is designed for high-reliability power rectification applications, featuring a 150V reverse voltage rating, fast 25ns recovery time and rugged hermetically sealed construction. Qualified under MIL-PRF-19500/477, JTX1N5806 is suitable for military, aerospace, space and industrial applications requiring dependable switching performance and long-term reliability. :contentReference[oaicite:0]{index=0}
Key Features
Manufacturer: Microchip Technology / Microsemi
Part Number: JTX1N5806
Device Type: Fast Recovery Rectifier Diode
Product Category: Discrete Semiconductor / Rectifier
Diode Configuration: Single Diode
Technology: Silicon Fast Recovery Rectifier
Reverse Voltage (VRRM): 150V
Average Rectified Current (IO): 1A
Peak Forward Surge Current: High Surge Capability
Forward Voltage Drop (VF): Approximately 0.875V at 1A
Reverse Recovery Time (trr): 25ns
Fast Recovery Performance
Low Forward Power Loss
Low Reverse Leakage Current
High Switching Speed Capability
Controlled Avalanche Capability
High Reliability Metallurgical Bond Construction
Hermetically Sealed Glass Package
Radiation Hardened Design Capability
Qualification: MIL-PRF-19500/477
Military Grade Component
Operating Junction Temperature: -65°C to +175°C
Package Type: Axial Glass Package
Mounting Type: Through-Hole
Application Type: High Reliability Rectification
Typical Applications: Switching Power Supplies, Military Power Systems, Aerospace Electronics, High-Speed Rectifiers and Pulse Power Circuits
Product Status: Active / Military Qualified Component
Replacement Note: Verify voltage rating, current rating, recovery time, package style and qualification level before replacement.
Applications
JTX1N5806 is designed for high-reliability rectification applications where fast switching performance and rugged construction are required. Typical applications include military power supplies, aerospace electronics, spacecraft systems, switching regulators, inverter circuits, pulse circuits and industrial equipment requiring MIL-qualified semiconductor components. :contentReference[oaicite:1]{index=1}
Quality & Sourcing
Antrex Electronics provides JTX1N5806 sourcing support including inventory verification, RFQ quotation, manufacturer authentication, package confirmation, date code inspection and shipment coordination. OEMs, EMS providers, aerospace contractors, military equipment manufacturers and electronic component buyers are welcome to submit BOM lists or high-reliability semiconductor sourcing requirements.
Quality inspection services include product photos, marking verification, visual inspection and third-party testing support when required to ensure reliable component supply.
