5962-9308501MXC

Product Overview

5962-9308501MXC is commonly associated with Lattice Semiconductor ispLSI 1032-60LG/883 / ISPLSI 1032 family military-grade complex programmable logic devices. The device is an electrically erasable CMOS programmable logic IC designed for custom digital logic, address decoding, state-machine control and glue logic replacement in high-reliability systems. With 128 macrocells, 64 I/O pins, 6000-gate class logic capacity, 5V operation, in-system programmable support, 4 external clock inputs and 84-pin CPGA package, it is suitable for aerospace electronics, defense digital systems, avionics logic boards, industrial control equipment, test systems and legacy CPLD replacement projects.

Key Features

• Manufacturer: Lattice Semiconductor

• Marking / Short Part Number: 5962-9308501MXC

• Full / Related Part Number: ispLSI 1032-60LG/883, ISPLSI 1032, 5962-9308501MXC and related Lattice military CPLD variants

• Device Type: Complex programmable logic device / CPLD

• Product Category: Programmable logic IC / CPLD

• Logic Family: Lattice ispLSI / pLSI 1032 programmable logic family

• Logic Capacity: 6000-gate class

• Number of Macrocells: 128 macrocells

• Number of I/O Pins: 64 I/O pins

• Logic Array Blocks: 32 logic array blocks

• Propagation Delay: 20ns to 25ns class depending on speed grade and datasheet condition

• Maximum Operating Frequency: 38MHz to 60MHz class depending on speed grade and timing condition

• Supply Voltage: 5V class operation, typically 4.5V to 5.5V

• Programming Feature: Electrically erasable and in-system programmable logic device

• Clock Feature: 4 external clock inputs

• Operating Temperature Range: -55°C to +125°C military temperature range

• Package Type: 84-pin ceramic pin grid array / CPGA package

• Mounting Type: Through-hole / socketable CPGA mounting depending on board design

• Key Features: 128 macrocells, 64 I/O pins, 6000-gate class logic capacity, 5V operation, in-system programmability, 4 external clocks, military temperature support and 84-pin CPGA package

• Typical Use: Custom glue logic, address decoding, state machines, control logic, chip select generation, legacy PLD replacement and high-reliability digital systems

• Ordering / Packaging Note: 5962-9308501MXC is a military SMD ordering reference for Lattice ispLSI 1032 military CPLD variants; buyers should verify the full Lattice ordering code, SMD drawing revision, programmed JEDEC file, package type, speed grade, top marking, date code, traceability documents and datasheet revision before production, aerospace or defense repair use.
