F4-75R12MS4

Product Overview

F4-75R12MS4 is an Infineon Technologies EconoDUAL™2 high-performance IGBT power module designed for high-frequency switching applications. This module integrates fast IGBT2 technology with a free-wheeling diode and built-in NTC temperature sensor, providing low switching losses, high power density and reliable thermal monitoring. With a 1200V collector-emitter voltage rating and 75A continuous collector current capability, it is suitable for industrial motor drives, renewable energy converters, UPS systems, welding equipment and high-frequency power conversion applications.

Key Features

• Manufacturer: Infineon Technologies

• Part Number: F4-75R12MS4

• Product Type: IGBT Power Module

• Series: EconoDUAL™2

• Technology: Fast IGBT2 Technology

• Configuration: Quad IGBT Module

• Collector-Emitter Voltage (VCES): 1200V

• Collector Current (IC): 75A

• Repetitive Peak Collector Current (ICRM): 150A

• Gate-Emitter Voltage (VGES): ±20V

• Maximum Power Dissipation: 500W

• Collector-Emitter Saturation Voltage: Low VCE(sat) characteristic

• Switching Performance: Optimized for high-frequency switching

• Integrated Components: IGBT chips, free-wheeling diodes and NTC temperature sensor

• Short Circuit Capability: High short-circuit withstand capability

• Thermal Monitoring: Built-in NTC temperature sensor

• Isolation Voltage: Electrically isolated base plate design

• Package Type: EconoDUAL™2 module package

• Mounting Type: Screw mounting

• Operating Temperature Range: -40°C to +125°C

• Cooling Method: Heatsink cooling

• Compliance: RoHS compliant

• Typical Applications: Motor drives, industrial inverters, UPS systems, welding equipment, solar inverters and power conversion systems

• Features: Low switching losses, high power density, fast switching capability and reliable thermal performance

• Lifecycle Status: Obsolete product; availability should be confirmed before purchase.

Applications

F4-75R12MS4 is designed for power electronics systems requiring efficient high-speed switching and compact power modules. Typical applications include industrial motor controllers, frequency converters, servo drives, renewable energy systems, UPS equipment, induction heating systems and high-frequency switching converters. The module is especially suitable for applications where low switching losses and high power density are required.
