FMV14N25G
N-channel power MOSFET featuring 250V voltage rating, low resistance and high switching efficiency
Quick Answer: FMV14N25G is a Fuji Electric SuperFAP series N-channel silicon power MOSFET designed for medium-voltage switching applications.
- Manufacturer
- Fuji Electric Co., Ltd.
- Product Category
- MOSFET
- Package
- TO220F
- Stock
- 1,500 pcs
- Availability
- Current quantity subject to confirmation.
Product Attributes
| Manufacturer | Fuji Electric Co., Ltd. |
|---|---|
| Product Category | MOSFET |
| Applications | Switching Power Supplies, Inverters, Motor Control |
| Avalanche Rated | Yes |
| Channel Temperature | 150°C |
| Drain Current (Id) | 14A |
| Drain-Source On Resistance (RDS(on)) | 0.35Ω typ. |
| Drain-Source Voltage (VDS) | 250V |
| Gate Threshold Voltage (VGS(th)) | 2.0V to 4.0V |
| Gate-Source Voltage (VGS) | ±30V |
| High Speed Switching Capability | Yes |
| Input Capacitance (Ciss) | 1500pF typ. |
| Lead Configuration | 3 Leads |
| Low Switching Loss Design | Yes |
| Maximum Power Dissipation | 150W |
| Mounting Style | Through Hole |
| Operating Temperature Range | -55°C to +150°C |
| Output Capacitance (Coss) | 220pF typ. |
| Package Type | TO-220 |
| Product Category | Power MOSFET |
| Reverse Transfer Capacitance (Crss) | 70pF typ. |
| RoHS Compliance | Compliant |
| Transistor Type | N-Channel MOSFET |
| Datasheet | Request Datasheet |
Procurement Snapshot
Key supply and purchasing information for FMV14N25G.
Why Source from Antrex Electronics?
Independent distribution support for verified sourcing, inspection and international procurement requirements.
Independent Distribution Support
Shortage, obsolete and hard-to-find component sourcing for production and procurement requirements.
Traceability Review
Label, lot, date code and available supply-chain documentation can be reviewed before order confirmation.
Inspection & Testing
Visual inspection, X-ray and third-party testing support can be arranged when required.
Global Procurement Support
Support for OEM, EMS, distributors and international sourcing requirements across individual parts and BOM projects.
Credentials & Verification Support
Quality controls, traceability review and inspection support for electronic component sourcing.
Detailed Description for FMV14N25G
Product Overview
FMV14N25G is a Fuji Electric SuperFAP series N-channel silicon power MOSFET designed for medium-voltage switching applications. The device features a 250V drain-source voltage rating, high current capability and optimized switching performance for efficient power conversion. With low conduction loss, fast switching characteristics and reliable avalanche capability, it is suitable for industrial power supplies, motor control circuits, switching regulators, inverter equipment and general-purpose power switching applications. ([Fuji Electric](https://products.fujielectric.com/en/semiconductor/search/parametric/power_mosfet/) )
Key Features
Manufacturer: Fuji Electric
Part Number: FMV14N25G
Device Type: N-Channel Power MOSFET
Product Category: Power Semiconductor Transistor
Series: SuperFAP Series
Channel Type: N-Channel Enhancement Mode
Drain-Source Voltage (VDS): 250V
Continuous Drain Current (ID): 14A
Gate-Source Voltage (VGS): ±30V
Low Drain-Source On Resistance: Designed for Reduced Conduction Loss
Switching Performance: High-Speed Switching Capability
Avalanche Capability: High Avalanche Energy Performance
Gate Drive: Voltage-Controlled Gate Operation
Technology: Silicon Power MOSFET Process
Power Dissipation: High Thermal Performance Design
Operating Temperature Range: -55°C to +150°C
Package Type: TO-220 / Power Through-Hole Package (Verify Exact Version)
Mounting Type: Through Hole
Terminal Configuration: Drain, Gate and Source
Insulation Structure: Package Isolation Depending on Variant
Typical Applications: Switching Power Supplies, DC-DC Converters, Motor Drives, Industrial Controllers and Inverter Circuits
Product Status: Legacy / Obsolete Component
Replacement Note: Buyers should verify voltage rating, current rating, RDS(on), package type, pin configuration and switching parameters before replacement selection.
Datasheet PDF: Fuji Electric Power MOSFET Datasheet
Applications
FMV14N25G is suitable for power switching systems requiring reliable medium-voltage MOSFET performance. Typical applications include industrial power converters, switching regulators, motor control equipment, inverter circuits, automation equipment, power management systems and repair projects involving Fuji Electric legacy semiconductor devices.
Quality & Sourcing
Antrex Electronics can support FMV14N25G sourcing with stock availability checks, RFQ quotation, manufacturer verification, package confirmation, date code review and shipment arrangement. For legacy MOSFET requirements, buyers can provide quantity, acceptable date codes, packaging requirements and application information for faster quotation support.
For quality control, Antrex Electronics can help arrange product photos, marking review, visual inspection, electrical testing and third-party verification when required. OEMs, EMS providers, industrial equipment manufacturers, repair centers and electronic component buyers are welcome to send BOM lists or hard-to-find semiconductor requests for sourcing assistance.
Datasheet
